Product Name: 3300 XL 8 mm Probe
Brand Name: Bently Nevada
Model Number: 330101-00-76-05-01-00
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | 3300 XL 8 mm Probe |
| Brand Name | Bently Nevada |
| Model Number | 330101-00-76-05-01-00 |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | Bently Nevada 330101-00-76-05-01-00 3300 XL 8 mm Probe |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Probe |
| Part Number | 330101-00-76-05-01-00 |
| Dimensions | 57.8x1.2x1.2cm |
| Weight | 0.1kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Condition | New & Original in Factory Packing |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Operating and Storage Temperature | -52°C to +177°C (-62°F to + 350°F) |
| Probe Relative Humidity | Less than a 3% change in Average Scale Factor (ASF) when tested in 93% humidity in accordance with IEC standard 68 2 3 for up to 56 days |
| Unthreaded Length Option | 0.0 in |
| Overall Case Length Option | 7.6 in |
| Total Length Option | 0.5 meter (1.6 feet) |
| Connector and Cable-Type Option | Miniature coaxial ClickLoc connector with connector protector, standard cable |
| Agency Approval Option | Not required |
The Bently Nevada 330101-00-76-05-01-00 3300 XL 8 mm Probe is a high-precision eddy-current proximity probe designed for continuous vibration and position monitoring in rotating machinery protection systems. It operates on the principle of non-contact measurement, detecting changes in the gap between the probe tip and a conductive target and converting them into proportional electrical signals for accurate condition monitoring.
Built with a PPS probe tip and AISI 303/304 stainless steel housing, it is engineered for durability and stable operation in harsh industrial environments. Its strong environmental resistance and stable calibration performance make it suitable for long-term industrial monitoring applications.
The Bently Nevada 330101-00-76-05-01-00 3300 XL 8 mm Probe features a total length of 0.5 meters (1.6 feet) and an overall case length of 7.6 inches, with no unthreaded length (0.0 in option). It uses a miniature coaxial ClickLoc connector with protective sleeve and standard cable for secure and reliable connections.
The probe tip is made of polyphenylene sulfide (PPS), while the housing is constructed from AISI 303 or 304 stainless steel. It operates in a wide temperature range from -52°C to +177°C (-62°F to +350°F). Under high humidity conditions (93% RH, IEC 68-2-3 standard), it maintains less than 3% change in average scale factor (ASF), ensuring measurement stability. The unit weighs 0.1 kg and measures 57.8 × 1.2 × 1.2 cm.
Provides high-accuracy, non-contact measurement, eliminating mechanical wear and extending operational life
Robust stainless steel construction ensures strong resistance to corrosion, temperature extremes, and harsh industrial environments
Maintains high measurement stability even under long-term humidity exposure, ensuring reliable and consistent data output
ClickLoc connector with protective design simplifies installation and maintenance while improving connection reliability
Compact and lightweight design allows flexible installation in various machinery configurations without performance loss
Widely used in vibration monitoring and protection systems for rotating equipment such as turbines, compressors, pumps, and generators
Commonly applied in industries including power generation, oil and gas, petrochemical processing, and heavy manufacturing
Particularly suitable for standard industrial rotating machinery requiring continuous condition monitoring and performance evaluation
This Bently Nevada 330101-00-76-05-01-00 3300 XL 8 mm Probe plays a key role in machinery diagnostics by continuously measuring shaft vibration and displacement. It enables early detection of faults such as imbalance, misalignment, shaft eccentricity, and mechanical looseness.
By delivering stable real-time data, it supports predictive maintenance strategies and helps prevent unexpected equipment failures. Integrated into protection systems, it enhances operational safety, improves reliability, and reduces downtime by ensuring early fault identification and accurate machine condition assessment.
