Product Name: VME CARRIER CARD
Brand Name: General Electric
Model Number: VIPC616
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | GE VIPC616 VME CARRIER CARD |
| Manufacturer | General Electric |
| Product Type | VME CARRIER CARD |
| Part Number | VIPC616 |
| Weight | 0.38kg |
| Estimated shipping dimensions | 2.1x18.8x26.2cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| VMEbus Form Factor | 6U (double high) |
| IndustryPack® Conformance | ANSI/VITA 4— 1996 |
| IP ID PROM Mapping | A16, 128 bytes/IP |
| IP Memory Mapping | A24 or A32 |
| Memory Size | None, or 128 kbytes to 4 MB in 6 |
| VMEbus Interrupt | IRQ1 through IRQ7 |
| Power Requirements | + 5 V @ 610 mA typical |
| Environmental | 0 o C to 70o C operating |
| IndustryPack Carrier Card | VME System Interface Card |
| GE VME Interface Card | High Reliability Carrier Card |
| VIPC616 VME Board | 6U VME Bus Module |
| Industrial VMEbus Hardware | Industrial Control Hardware |
| GE Automation Platform Card | Modular VME Carrier System |
| Embedded Control Carrier Card | Embedded System Expansion Card |
| ANSI/VITA 4 Carrier Module | Real-Time Control VME Card |
| VMEbus Expansion Card | GE Legacy Automation Module |
| IP Module Carrier Board | Industrial Computing Interface Card |
| GE Industrial Electronics | VMEbus Backplane Module |
The GE VIPC616 is a 6U VME carrier card designed to support IndustryPack (IP) modules in VMEbus-based industrial control systems. It provides a flexible and modular platform for integrating application-specific I/O and communication functions in embedded automation and real-time control environments.
Built to ANSI/VITA standards, the VIPC616 enables reliable operation within VME systems and supports a wide range of IP modules for customized industrial applications. It is commonly used in high-performance control systems, embedded computing platforms, and legacy automation architectures.
IndustryPack Module Hosting
The GE VIPC616 provides a VME carrier platform for installing IndustryPack (IP) modules, enabling flexible system expansion.
VMEbus Interface Integration
Acts as an interface between IP modules and the VMEbus backplane for stable data and control communication.
Memory Mapping Support
Supports A16, A24, and A32 addressing schemes to ensure compatibility with different IP module configurations.
Interrupt Handling Capability
Provides VMEbus interrupt support (IRQ1–IRQ7) for efficient event-driven communication in real-time systems.
Power Distribution to Modules
Supplies regulated +5 V power to installed IP modules, ensuring stable operation within the carrier environment.
Modular System Expansion
Enables flexible addition of multiple IP modules to extend system functionality in embedded control applications.
Industrial Environment Operation
Designed to operate reliably in temperatures from 0°C to 70°C for industrial-grade performance.
Embedded Control Support
Supports integration in real-time embedded systems for customized industrial automation solutions.
Compared with other VME carrier cards, the GE VIPC616 offers strong IndustryPack compatibility, flexible memory mapping options, and reliable industrial-grade operation, making it suitable for embedded and real-time control systems.
Strong IndustryPack Compatibility: Fully supports ANSI/VITA 4-1996 compliant IP modules.
Flexible Memory Mapping: Supports both A24 and A32 addressing for adaptable system design.
Reliable VMEbus Integration: Provides stable operation within 6U VMEbus architectures.
Efficient Modular Expansion: Allows easy integration of multiple IP modules for customized functions.
Industrial-Grade Durability: Designed for operation in 0°C to 70°C environments.
Stable Power Delivery: Supplies consistent +5 V power for reliable module performance.
Robust Interrupt Handling: Supports IRQ1–IRQ7 for efficient system-level communication.
What is GE VIPC616 used for?
The GE VIPC616 is used as a VME carrier card to host IndustryPack modules in VMEbus-based industrial control systems.
What form factor does GE VIPC616 use?
The GE VIPC616 uses a 6U double-high VMEbus form factor.
What types of modules does GE VIPC616 support?
The GE VIPC616 supports IndustryPack (IP) modules compliant with ANSI/VITA 4-1996 standards.
What memory mapping does GE VIPC616 support?
The GE VIPC616 supports A24 and A32 memory mapping configurations.
What is the operating temperature of GE VIPC616?
The GE VIPC616 operates in a temperature range from 0°C to 70°C.
How is GE VIPC616 powered?
The GE VIPC616 is powered by +5 V DC with a typical current draw of 610 mA.
What interrupt levels does GE VIPC616 support?
The GE VIPC616 supports VMEbus interrupts from IRQ1 through IRQ7.
