Product Name: OP17/DP-12 MBaud Operator Panel
Brand Name: Siemens
Model Number: 6AV3617-1JC30-0AX1
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6AV3617-1JC30-0AX1 OP17/DP-12 MBaud Operator Panel |
| Manufacturer | Siemens |
| Product Type | OP17/DP-12 MBaud Operator Panel |
| Part Number | 6AV3617-1JC30-0AX1 |
| Weight | 0.8kg |
| Estimated shipping dimensions | 24x20.3x5.3cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Type of supply voltage | 24 V DC |
| UPS connectable (serial) | No |
| Current consumption (rated value) | 0.34 A |
| Active power input, typ. | 10 W |
| Processor type | X86 |
| Type of memory | Flash / RAM |
| Memory available for user data | 256 kbyte |
| Backup battery optional | 3.6 V |
| Backup time, min. | 4 y |
| Mounting position | vertical |
| Design of display | LC display |
| Color type | Black/white |
| Number of lines | 8 |
| Number of characters per line | 40 |
The Siemens 6AV3617-1JC30-0AX1 OP17/DP Operator Panel is a compact human-machine interface (HMI) designed for monitoring and controlling industrial automation systems. It provides operators with real-time visualization of machine status, process parameters, and alarm information, enabling efficient interaction with PLC-based control systems, particularly in SIMATIC environments.
This operator panel features a monochrome LC display with 8 lines of 40 characters, offering clear and structured process feedback. Designed for PROFIBUS DP communication at 12 Mbaud, it ensures reliable and fast data exchange between the control system and the operator interface, making it suitable for a wide range of industrial applications such as manufacturing lines, process control, and machine operation.
Operator Control Interface
Provides a user interface for monitoring and controlling PLC-driven industrial processes in real time.
Process Visualization
Displays machine status, process values, and system alarms on an 8-line LC screen for operator interaction.
PLC Communication Interface
Enables data exchange with SIMATIC PLC systems via PROFIBUS DP at up to 12 Mbaud.
Alarm and Event Display
Shows system alarms and events to support fault diagnosis and operational awareness.
Parameter Adjustment
Allows operators to modify process parameters directly from the panel interface.
Data Storage & Handling
Stores user programs and operational data in Flash/RAM memory for stable system operation.
System Integration
Integrates into Siemens automation architectures as a dedicated HMI terminal for machine-level control.
Compared to other operator panels in its class, the Siemens 6AV3617-1JC30-0AX1 stands out for its high communication reliability, simple and stable interface design, and strong integration with SIMATIC systems, making it a dependable and efficient HMI solution for industrial control applications.
The Siemens 6AV3617-1JC30-0AX1 OP17/DP Operator Panel delivers stable and efficient operator interaction for industrial automation systems. With PROFIBUS DP communication at up to 12 Mbaud, it ensures fast and reliable data exchange between PLC systems and the operator interface, enabling real-time monitoring and control of industrial processes.
Its x86 processor architecture and optimized memory design (256 kB Flash/RAM) provide smooth and consistent performance for text-based visualization and control tasks. With a typical power consumption of around 10 W and robust industrial-grade construction, the OP17/DP ensures reliable long-term operation with minimal maintenance requirements in demanding industrial environments.
