Siemens 6DD1682-0BC3 SIMADYN D SR12 subrack system Original new

Siemens 6DD1682-0BC3 SIMADYN D SR12 subrack system Original new

Product Name:SIMADYN D SR12 subrack system

Brand Name:Siemens

Model Number:6DD1682-0BC3

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6dd1682 0bc3 simadyn d sr12 subrack system original new-1

Overview
How to get price
Specifications
Description
Applications
Features & Benefits
High-Resolution Measurement
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6DD1682-0BC3
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

How to get price

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6DD1682-0BC3, SIMADYN D SR12.3 subrack system designed for industrial automation module integration and centralized control architecture
System Type	Subrack platform for SIMADYN D modules, enabling structured installation and high-reliability control system expansion
Supply Voltage	115/230 V AC dual-range input, supporting flexible industrial power integration
Cooling System	Equipped with fan-assisted cooling design, ensuring thermal stability under continuous operation
Bus System	Integrated L-bus and C-bus architecture for high-speed internal module communication
Module Capacity	Supports multiple SIMADYN D plug-in modules for scalable automation configuration
Protection Design	Built-in line filter for EMI suppression, ensuring stable operation in noisy industrial environments
Dimension	Width 298.5 mm, Height 508.5 mm, Depth 320 mm, rack-mounted industrial enclosure design
Weight	Approx. 10.5–11 kg, heavy-duty structural design for industrial cabinet installation

Description

The 6DD1682-0BC3 is a SIMADYN D SR12 subrack system designed for hosting and interconnecting industrial automation modules in high-performance drive and control applications. It provides a stable mechanical platform for SIMADYN D modules, ensuring reliable signal routing and power distribution through integrated backplane architecture.

As part of the SR12 series, including variants such as SR12.1 and SR12.4, this subrack supports both AC and DC supply configurations with optional fan cooling systems. It enables seamless communication between modules via L-bus and C-bus structures, ensuring efficient data exchange in distributed control environments.

The 6DD1682-0BC3 is engineered for demanding industrial installations requiring modular scalability, electromagnetic compatibility, and long-term operational stability. Its robust rack design supports complex automation systems used in process control, drive engineering, and power management applications.

Applications

Power plants: Used for generator control systems, monitoring, and relay protection for stable energy operation.
Substations: Enables bus differential control, switching logic, and real-time signal acquisition in grid systems.
Chemical plants: Supports process automation and intrinsically safe signal processing in hazardous environments.
Steel mills: Provides robust control performance under high temperature and strong electromagnetic interference conditions.
Machinery manufacturing: Used in automated production lines, robotics control, and packaging system integration.

Features & Benefits

Modular subrack design: Supports flexible SIMADYN D system expansion and structured control architecture.
Dual backplane buses (C-bus/L-bus): Ensures fast and synchronized communication between connected modules.
Wide AC voltage support: Compatible with 115 V and 230 V industrial power systems.
Integrated fan cooling: Maintains stable thermal conditions for long-term continuous operation.
High mechanical stability: Strong rack structure ensures secure module mounting in vibration-prone environments.
Reliable system integration: Designed for seamless compatibility with SIMATIC S7 and SIMADYN D platforms.

High-Resolution Measurement

Stable system timing: Supports precise synchronization of distributed control modules across the backplane bus.
Low signal distortion: Ensures clean data transmission within C-bus and L-bus communication lines.
High-accuracy module coordination: Maintains consistent signal alignment between CPU and interface modules.
Reduced electrical noise impact: Optimized grounding and shielding improve measurement stability in industrial environments.
Reliable long-distance coupling: Supports up to 102 m inter-module communication without signal degradation.
Consistent voltage regulation: Stable 5 V / ±15 V distribution improves overall system measurement precision.

FAQ

Q1: What is 6DD1682-0BC3 used for?
A1: It is a SIMADYN D SR12 subrack used to mount and connect automation modules in industrial control systems.

Q2: What voltage does this subrack support?
A2: It supports 115/230 V AC dual-range industrial power input.

Q3: Does it include cooling functionality?
A3: Yes, it includes fan-assisted cooling for stable thermal performance.

Q4: What communication buses are integrated?
A4: It uses L-bus and C-bus backplane systems for internal module communication.

Q5: Is it suitable for harsh environments?
A5: Yes, it is designed for industrial environments with electrical noise, vibration, and continuous operation demands.
