Siemens 6ES7131-4BD00-0AA0 compact digital input module Original new

Siemens 6ES7131-4BD00-0AA0 compact digital input module Original new

Product Name:compact digital input module

Brand Name:Siemens

Model Number:6ES7131-4BD00-0AA0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7131 4bd00 0aa0 compact digital input module original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7131-4BD00-0AA0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	6ES7131-4BD00-0AA0, SIMATIC ET 200S 4-channel Digital Input Module.
Product Type:	Standard 24 V DC digital input module for distributed ET 200S I/O systems.
Digital Inputs:	Four digital input channels with IEC 61131-2 Type 1 input characteristics.
Rated Input Voltage:	24 V DC operating voltage supplied through the ET 200S power module.
Input Signal Range:	Logic "0": -30 to +5 V DC, Logic "1": +15 to +30 V DC.
Input Current:	Typical input current of 7 mA per channel at 24 V DC.
Cable Length:	Supports shielded cables up to 1000 m and unshielded cables up to 600 m.
Protection Features:	Reverse polarity protection, electrical isolation from the backplane bus, LED input status indicators.
Dimensions:	15 × 81 × 52 mm, ultra-slim design for high-density cabinet installation.
Weight:	Approximately 35 g, lightweight module suitable for compact automation systems.

Description

The Siemens 6ES7131-4BD00-0AA0 is a compact digital input module developed for the SIMATIC ET 200S distributed I/O platform, providing four 24 V DC digital input channels for reliable industrial signal acquisition. Designed with a slim 15 mm housing, it enables efficient cabinet utilization while delivering dependable performance for a wide range of factory automation applications.

As a member of the SIMATIC ET 200S modular I/O family, 6ES7131-4BD00-0AA0 features reverse polarity protection, IEC 61131 Type 1 input characteristics, electrical isolation from the backplane bus, and compatibility with both standard switches and 2-wire sensors. Its long cable support allows flexible installation in distributed control systems.

Engineered for industrial automation, 6ES7131-4BD00-0AA0 is widely applied in manufacturing, power generation, water treatment, logistics, and machine control systems where accurate digital signal monitoring, space-saving installation, and dependable operation are essential.

Applications

Power plants: Used for collecting digital status signals from generators, auxiliary equipment, and protection systems.
Substations: Monitor switch positions, circuit breaker status, and digital field signals for automation systems.
Chemical plants: Acquire process input signals from field switches, sensors, and control devices.
Steel mills: Perform digital signal monitoring in production lines exposed to vibration, heat, and electromagnetic interference.
Machinery manufacturing plants: Connect pushbuttons, limit switches, proximity sensors, and automated production equipment.
Water treatment facilities: Collect operating status signals from pumps, valves, and field instrumentation for centralized control.

Features

Four 24 V DC digital input channels.
Compact 15 mm module for space-saving installation.
Designed for SIMATIC ET 200S distributed I/O systems.
IEC 61131-2 Type 1 input compliance.
Reverse polarity protection for improved reliability.
Supports long-distance shielded and unshielded cable connections.
LED indicators provide clear channel status monitoring.
Electrical isolation between field wiring and backplane bus.

Functions

Receives digital input signals from industrial field devices.
Monitors switches, sensors, and contact signals accurately.
Transfers field input data to the PLC control system.
Supports distributed automation architectures with ET 200S.
Improves system reliability through stable signal acquisition.
Enables efficient machine monitoring and process control.
Simplifies installation with compact modular construction.

FAQ

Q1: What is the primary purpose of 6ES7131-4BD00-0AA0?
A1: It is a four-channel digital input module designed for acquiring 24 V DC field signals in SIMATIC ET 200S systems.

Q2: How many digital input channels does 6ES7131-4BD00-0AA0 provide?
A2: The module provides four independent digital input channels for industrial automation applications.

Q3: Is 6ES7131-4BD00-0AA0 compatible with 2-wire sensors?
A3: Yes. The module supports compatible 2-wire sensors within the specified electrical characteristics.

Q4: Does 6ES7131-4BD00-0AA0 include diagnostic functions?
A4: It does not provide advanced diagnostics, but it includes LED indicators for input channel status monitoring.

Q5: Which industries commonly use 6ES7131-4BD00-0AA0?
A5: It is widely used in power generation, manufacturing, water treatment, chemical processing, logistics, and machinery automation systems requiring reliable digital input acquisition.
