Home > Products > SIEMENS > SIMATIC S7 Series
Distributed PROFIBUS DP base module with eight digital inputs, M12 connections and integrated sensor supply.
Sales |
Jim Pei |
Email |
|
Phone/Whatsapp |
|
Model Number
|
6ES7141-1BF12-0XB0
|
|
Digital inputs
|
8
|
|
Input rated voltage
|
24 V DC
|
|
Signal 0 voltage
|
-3 to +5 V
|
|
Signal 1 voltage
|
13 to 30 V
|
|
Signal 1 current, typical
|
7 mA
|
|
Input delay, rising edge
|
1.2–4.8 ms
|
|
Input delay, falling edge
|
1.2–4.8 ms
|
|
Unshielded input cable length, maximum
|
30 m
|
|
2-wire sensor quiescent current, maximum
|
1.5 mA
|
|
Load supply 1L+ rated voltage
|
24 V DC
|
|
Supply current from 1L+, maximum
|
180 mA
|
|
Sensor supply outputs
|
4
|
|
Sensor supply current up to 40 °C, maximum
|
0.9 A
|
|
Sensor supply current up to 55 °C, maximum
|
0.7 A
|
|
Power loss, typical
|
3.5 W
|
|
Expansion modules, maximum
|
7
|
|
Motor starter / converter expansions, maximum
|
6
|
|
Pneumatic interface expansions, maximum
|
6
|
|
Simultaneous inputs up to 55 °C
|
8
|
|
PROFIBUS data rate, maximum
|
12 Mbit/s
|
|
Input characteristic
|
IEC 61131 Type 1
|
|
Connector configuration
|
5-pole M12, double assigned
|
|
Ingress protection
|
IP66 / IP67
|
|
1L+ short-circuit protection
|
Electronic
|
|
1L+ reverse polarity protection
|
Provided
|
|
2L+ reverse polarity protection
|
Not provided
|
|
Sensor supply short-circuit protection
|
Electronic
|
|
Input channel isolation
|
No isolation between channels
|
|
Load voltage isolation
|
Isolated from other switching components
|
|
PROFIBUS isolation
|
Isolated from other circuit components
|
|
beMinimum Order Quantity
|
1 Piece
|
|
Price
|
Contact for Jim
|
|
Packaging Details
|
Original new Factory Sealed
|
|
Delivery Time
|
3–7 Days
|
|
Payment Terms
|
T/T
|
|
Shipping Method
|
DHL / FedEx / UPS / TNT
|
|
Supply Ability
|
In stock
|
Siemens 6ES7141-1BF12-0XB0 is a SIMATIC ET 200X BM 141 basic module for distributed digital input acquisition. Eight inputs accept industrial sensor signals through double-assigned M12 connections. The base incorporates a PROFIBUS DP slave interface for exchange with the automation controller. Integrated sensor supply distributes power to connected field devices. Its protected enclosure supports decentralized installation close to the machine.
The 6ES7141-1BF12-0XB0 provides the starting point for an expandable ET 200X station. Additional modules extend the station within the specified configuration limits. Status and diagnostic LEDs help personnel distinguish input states from bus and supply faults. Parameterizable diagnostics support commissioning and maintenance. Match the station configuration, connector assignment and sensor power requirements before installing a replacement.
Acquires discrete field signals near the machine through the ET 200X base.
Provides the base for supported ET 200X expansion modules.
Connects decentralized input information to the PROFIBUS DP controller.
Sensor powering — Integrated protected outputs distribute the sensor supply.
Fault indication — Bus, group-error and input-state indicators assist local checks.
Replacement planning — Check the complete ET 200X station and M12 pin assignment before exchange.
No. The basic module incorporates the PROFIBUS DP slave interface.
It is the BM 141 basic module; select expansion modules separately for the complete station.
Verify the double-assigned M12 connector pinout and sensor supply loading before connection.
Request photographs of the offered unit and available inspection information before shipment.
Dispatch is arranged immediately after payment is received for confirmed in-stock units.
Yes. Send the existing label and station configuration so we can check the exact offered article.
