Siemens 6ES7153-2BA10-0XB0 high-performance PROFIBUS DP interface module Original new

Siemens 6ES7153-2BA10-0XB0 high-performance PROFIBUS DP interface module Original new

Product Name:PROFIBUS DP interface module

Brand Name:Siemens

Model Number:6ES7153-2BA10-0XB0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7153 2ba10 0xb0 high performance profibus dp interface module original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7153-2BA10-0XB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Product Model	6ES7153-2BA10-0XB0
Product Type	IM 153-2 DP HF Interface Module
Product Family	SIMATIC ET 200M
Communication Protocol	PROFIBUS DP (EN 50170)
Transmission Medium	RS-485
Transmission Rate	Up to 12 Mbit/s
Supply Voltage	24 VDC
Voltage Range	20.4 to 28.8 VDC
Current Consumption	Max. 650 mA
Backplane Bus Current	Max. 1.5 A
Power Dissipation	Typical 5.5 W
Number of S7-300 Modules	Up to 12
Input Address Area	244 Bytes
Output Address Area	244 Bytes
Time Stamping Accuracy	1 ms (up to 8 modules)
PROFIBUS Address Range	1 to 125
Protection Class	IP20
Dimensions (W × H × D)	40 × 125 × 117 mm
Weight	Approx. 360 g

Description

The 6ES7153-2BA10-0XB0 is a high-performance PROFIBUS DP interface module from the Siemens ET 200M distributed I/O family. Designed for advanced automation systems, it serves as the communication gateway between PROFIBUS networks and S7-300 I/O modules, enabling efficient data exchange and reliable field-level connectivity.

Featuring High Feature (HF) functionality, the 6ES7153-2BA10-0XB0 supports up to twelve S7-300 modules per station and offers redundancy capability for applications requiring increased system availability. Enhanced features such as time stamping, isochronous mode support, HART integration, and slave-to-slave communication make it well suited for sophisticated industrial control environments.

As part of Siemens' distributed automation portfolio, the 6ES7153-2BA10-0XB0 integrates seamlessly with related ET 200M and SIMATIC systems, delivering scalable performance for process industries, manufacturing facilities, and infrastructure automation projects.

Applications

Power plants: Used for generator monitoring systems, turbine control, and relay protection networks.
Substations: Enables communication between distributed I/O stations and protection equipment.
Chemical plants: Integrates process control signals and HART-enabled instrumentation.
Steel mills: Supports distributed automation systems operating in harsh industrial environments.
Machinery manufacturing plants: Connects field devices, sensors, and actuators to centralized PLC systems.
Oil & gas facilities: Facilitates reliable communication between remote I/O stations and control systems.
Water treatment plants: Supports distributed process monitoring and automation applications.

Features

Supports up to 12 S7-300 I/O modules
PROFIBUS DP High Feature communication
Redundancy-capable architecture
Integrated time stamping functionality
Supports isochronous operation mode
Compatible with HART auxiliary variables
Slave-to-slave data exchange capability

Functions

Connects ET 200M stations to PROFIBUS networks
Transfers process data between PLC and field devices
Supports deterministic communication timing
Provides event time stamping for diagnostics
Enables distributed I/O expansion
Supports synchronized automation applications
Improves network reliability and availability

FAQ

Q1: What is the primary function of the 6ES7153-2BA10-0XB0?
A1: It acts as a PROFIBUS DP interface module connecting ET 200M distributed I/O stations to automation systems.

Q2: How many S7-300 modules can the interface support?
A2: The module supports up to twelve S7-300 I/O modules per ET 200M station.

Q3: Does the 6ES7153-2BA10-0XB0 support redundant configurations?
A3: Yes, it provides redundancy capability for high-availability industrial applications.

Q4: What communication protocol does the module use?
A4: It communicates through PROFIBUS DP using an RS-485 transmission interface.

Q5: Is time stamping available on this module?
A5: Yes, the module supports event time stamping with high accuracy for monitoring and diagnostics.
