Product Name: Siemens SIMATIC DP IM153-2 HF Interface Module
Brand Name: Siemens
Model Number: 6ES7153-2BA70-0XB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
| Sales | Phone/Whatsapp | |
| Jim Pei | [email protected] | +86 18020776782 |
| Manufacturer | Siemens |
| Product Family | SIMATIC DP / ET 200M |
| Product Type | Interface Module |
| Part Number | 6ES7153-2BA70-0XB0 |
| Module Designation | IM153-2 HF |
| Application | DP/PA Link / ET 200M Interface |
| Maximum S7-300 Modules per Station | 12 |
| Redundancy | Yes |
| Isochronous Mode | Yes |
| Time Stamping | Yes |
| Rated Supply Voltage | 24 VDC |
| Permissible Supply Voltage Range | 20.4–28.8 VDC |
| Recommended External Protection | 2.5 A |
| Mains / Voltage Failure Stored Energy Time | 5 ms |
| Maximum Current Consumption | 650 mA |
| Typical Inrush Current | 3 A |
| Maximum Backplane Bus Output Current @ 5 VDC | 1.5 A |
| Typical Power Loss | 5.5 W |
| Input Address Area | 244 Bytes |
| Output Address Area | 244 Bytes |
| Maximum Modules per DP Slave Interface | 12 |
| Time Stamp Accuracy | 1 ms up to 8 Modules; 10 ms up to 12 Modules |
| Number of Message Buffers | 15 |
| Messages per Message Buffer | 20 |
| Maximum Stampable Digital Inputs | 128 Signals per Station; Max. 32 Signals per Slot |
| Time Format | RFC 1119 |
| Time Resolution | 0.466 ns |
| Message Buffer Transmission Interval | 1,000 ms |
| Time Stamp Trigger | Rising / Falling Edge |
| Interface | RS-485 |
| Communication Protocol | PROFIBUS DP to EN 50170 |
| PROFIBUS DP Node Addresses | 1–125 |
| Maximum PROFIBUS DP Transfer Rate | 12 Mbit/s |
| PROFIBUS Connector | 9-Pin Sub-D |
| Isolation Test Voltage | 500 V |
| Protection Class | IP20 |
| Maximum Operating Altitude | 3,000 m |
| Minimum Order Quantity | 1 Piece |
| Price | Contact for Jim |
| Packaging Details | Original new Factory Sealed |
| Delivery Time | 3–7 Days |
| Payment Terms | T/T |
| Shipping Method | DHL / FedEx / UPS / TNT |
| Supply Ability | In stock |
The Siemens 6ES7153-2BA70-0XB0 is a SIMATIC DP IM153-2 HF Interface Module designed for ET 200M distributed I/O stations and DP/PA Link applications. It provides PROFIBUS DP communication with support for redundancy, isochronous operation, time stamping, and coordinated data exchange between distributed S7-300 I/O modules and the automation system. The 6ES7153-2BA70-0XB0 is well suited for process automation, distributed I/O, redundant control architectures, PROFIBUS networks, plant modernization, and maintenance of SIMATIC ET 200M systems.
