Product Name: IM153-2 DP/PA Link Interface
Brand Name: Siemens
Model Number: 6ES7153-2BA81-0XB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7153-2BA81-0XB0 IM153-2 DP/PA Link Interface |
| Manufacturer | Siemens |
| Product Type | IM153-2 DP/PA Link Interface |
| Part Number | 6ES7153-2BA81-0XB0 |
| Weight | 0.26kg |
| Estimated shipping dimensions | 4x11.8x12.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| Power loss, typ. | 4 W |
| Transmission rate, max. | 12 Mbit/s |
| Number of DP slaves, max. | 64 |
| Transmission rate, max. | 31.25 kbit/s; User view |
| Number of connectable PA field devices | 64 |
| Isolation tested with | 500 V AC |
| Operation, max. | 95% |
| Ambient temperature during operation min. | -25 °C |
| Ambient temperature during operation max. | 60 °C |
Siemens 6ES7153-2BA81-0XB0 IM153-2 DP/PA Link Interface Module is a robust industrial communication interface designed for integrating PROFIBUS DP and PROFIBUS PA field devices into distributed automation systems. It acts as a key link component in Siemens SIMATIC ET 200 distributed I/O systems, enabling reliable, high-speed data exchange between controllers and field-level instrumentation in demanding industrial environments.
This IM153-2 interface module is engineered to support seamless communication between DP master systems and PA field devices through a DP/PA link architecture. It enables efficient expansion of automation networks by allowing up to 64 DP slaves and up to 64 PA field devices, making it suitable for large-scale process automation applications such as oil & gas, chemical processing, water treatment, and manufacturing plants.
DP/PA Communication Gateway
Acts as an interface between PROFIBUS DP and PROFIBUS PA networks, enabling seamless communication between high-speed control systems and field-level instrumentation.
Field Device Integration
Allows PROFIBUS PA field devices to be incorporated into DP-based automation architectures, supporting up to 64 PA devices.
DP Slave Management
Supports connection and management of up to 64 PROFIBUS DP slaves, enabling flexible system expansion in distributed I/O networks.
Protocol Conversion & Data Handling
Performs real-time conversion and synchronization of data between DP and PA protocols to ensure consistent and accurate information flow.
High-Speed DP Communication Support
Enables PROFIBUS DP transmission rates up to 12 Mbit/s for fast and efficient controller-level communication.
PA Communication Support
Supports PROFIBUS PA operation at 31.25 kbit/s, optimized for process automation and field instrumentation.
Electrical Isolation Protection
Provides 500 V AC tested isolation to protect systems from electrical noise and ensure stable industrial operation.
Compared to similar DP/PA interface solutions, this 6ES7153-2BA81-0XB0 IM153-2 DP/PA Link Interface module offers a more unified and scalable architecture, combining strong environmental resilience, efficient communication handling, and simplified system
The 6ES7153-2BA81-0XB0 IM153-2 DP/PA Link Interface delivers stable and deterministic communication performance between high-speed PROFIBUS DP networks and lower-speed PA field devices, ensuring consistent process data exchange in real time. Its optimized internal architecture minimizes power loss (approximately 4 W typical), contributing to energy-efficient operation even in continuously running industrial systems. With support for up to 64 devices per network segment and reliable isolation design, the module maintains high system uptime and signal integrity under demanding electrical and environmental conditions, making it a dependable backbone component in large-scale automation infrastructures.
