Siemens 6ES7215-1AG40-0XB0 CPU 1215C Compact CPU Unit

Siemens 6ES7215-1AG40-0XB0 CPU 1215C Compact CPU Unit

Product Name: CPU 1215C Compact CPU Unit

Brand Name: Siemens

Model Number: 6ES7215-1AG40-0XB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7215 1ag40 0xb0 cpu 1215c compact cpu unit-1

Overview
Functions
Features
Contact Info
Commercial Terms
Parameter
Application Scenarios
Operating Environment
Recommended Products

Overview

The Siemens 6ES7215-1AG40-0XB0 is a CPU 1215C controller from the SIMATIC S7-1200 series. It is a compact, modular programmable logic controller designed for mid-level industrial automation applications, integrating processing, I/O handling, and communication functions within a single unit.

This CPU provides a balance of performance and scalability, making it suitable for modern automation systems that require flexible expansion, high-speed signal processing, and reliable industrial communication. Its integrated PROFINET interface and built-in I/O support enable efficient deployment in space-constrained control environments such as machine building and production line automation.

Functions

Central control for automation systems and machine processes
Digital and analog signal processing
High-speed counting (HSC) and pulse train output (PTO) control
Industrial communication via PROFINET and standard Ethernet protocols
Data retention during power loss without battery support
Expandable system control with additional signal and communication modules

Features

Power Supply: 24V DC (20.4–28.8V)
Memory: 200 KB work memory, 4 MB load memory (expandable via SIMATIC Memory Card)
Processing Speed: ~0.08 μs per bit operation
Integrated I/O:
- 14 digital inputs (6 high-speed counter capable up to 100 kHz)
- 10 digital outputs (4 PTO up to 100 kHz)
- 2 analog inputs + 2 analog outputs (10-bit resolution)
Communication:
- Integrated PROFINET interface with dual RJ45 ports (built-in switch)
- Supports up to 16 IO devices
- TCP/IP, ISO-on-TCP, UDP protocols
Expandability: Supports up to 8 signal modules and 3 communication modules
Retentive Memory: Up to 14 KB without battery backup
Low Power Loss: Approximately 12 W
Firmware: Version V4.6

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Parameter

Product Name	Siemens 6ES7215-1AG40-0XB0 CPU 1215C Compact CPU Unit
Manufacturer	Siemens
Product Type	CPU 1215C Compact CPU Unit
Part Number	6ES7215-1AG40-0XB0
Estimated shipping dimensions	13x10x7.5cm
Weight	0.36kg
Place of shipment	Xiamen, China
Country of origin	Germany
Firmware Version	V4.6
Supply Voltage	24 V DC (20.4 - 28.8 V)
Power Loss	12 W
Work Memory	200 KB
Load Memory	4 MB integrated, expandable with SIMATIC Memory Card
Processing Time	Bit operation 0.08 μs/instr.
Integrated Analog I/O	2 inputs, 2 outputs
PROFINET IO Devices	Up to 16 connectable

Application Scenarios

Industrial machine automation
Packaging and assembly lines
Conveyor and material handling systems
Small to medium-scale production systems
Motion control applications requiring high-speed signals
Process automation with mixed analog/digital control
Distributed IO systems in smart factories

Operating Environment

The Siemens 6ES7215-1AG40-0XB0 CPU 1215C is designed for deployment in standard industrial automation environments where reliability and continuous operation are required. It is typically installed inside electrical control cabinets on DIN rails, ensuring protection against dust, mechanical stress, and electrical interference.

The controller operates on a 24V DC industrial power supply and is intended for use in environments with electromagnetic noise, vibration, and temperature variations commonly found in factory floors. It communicates through industrial Ethernet (PROFINET) networks, making it suitable for integrated automation systems and distributed control architectures.
