Siemens SIMATIC S7-1200 6ES7215-1BG40-0XB0 CPU 1215C Compact CPU AC/DC/Relay

Siemens SIMATIC S7-1200 6ES7215-1BG40-0XB0 CPU 1215C Compact CPU AC/DC/Relay

SIEMENS · SIMATIC S7-1200 6ES7215-1BG40-0XB0 CPU 1215C Compact CPU AC/DC/Relay	Compact CPU CPU 1215C AC/DC/relay
Digital I/O: 14 DI / 10 relay DO · Analog I/O: 2 AI / 2 AO · Network: 2 PROFINET ports
Order check: Confirm the complete article number, firmware, power, output type and application before quotation. Email Inquiry WhatsApp [email protected] \| +86 18159889985

Overview
Applications
Data
Construction
Environment
Selection
Verification
Commerciald
Models
Recommended Products

Official product overview

6ES7215-1BG40-0XB0 CPU 1215C compact controller

The Siemens 6ES7215-1BG40-0XB0 is a SIMATIC S7-1200 CPU 1215C compact controller. Siemens specifies an AC/DC/relay design, two PROFINET ports, integrated digital and analog I/O, an AC 85 to 264 V supply range, and 200 KB program/data memory.

Lifecycle note: Commercial availability, condition and delivery status are subject to verification for the quoted unit.

Applications

System role

Compact control with onboard I/O and PROFINET

Compact control tasks within a verified SIMATIC S7-1200 system.
Local processing with fourteen 24 V DC digital inputs and ten 2 A relay outputs.
Integrated acquisition through two 0 to 10 V DC analog inputs and two 0 to 20 mA DC analog outputs.
PROFINET-connected automation using the two onboard ports; topology and device roles must be confirmed during engineering.

Selection note: Application suitability and system coordination must be confirmed before quotation.

Data

Siemens data sheet

Key technical values

Use the exact article number and the official Siemens data sheet when validating a project.

Product type	CPU 1215C AC/DC/relay
Firmware version	V4.7
Engineering software	STEP 7 V20 or higher
Supply	85 to 264 V AC; 47 to 63 Hz
Digital I/O	14 DI, 24 V DC; 10 DO relay, 2 A
Analog I/O	2 AI, 0 to 10 V DC; 2 AO, 0 to 20 mA DC
Communication	2 PROFINET ports
Program/data memory	200 KB
Dimensions / weight	130 x 100 x 75 mm; approximately 550 g

Construction

Integrated CPU, I/O and network construction

The compact CPU combines processing, AC power supply, digital I/O, analog I/O and two PROFINET ports in one SIMATIC S7-1200 device. The 130 mm wide housing must be installed with the clearances and wiring practices specified by Siemens.

Interface check: Confirm terminal allocation, relay loads, analog ranges, network topology and expansion requirements.

Environment

Protection and environment

Installation conditions

Apply the limits and approvals stated for the exact Siemens article.

Operating temperature	-20 to 60 °C horizontal; -20 to 50 °C vertical, subject to Siemens derating notes
Storage / transport	-40 to 70 °C
Relative humidity	Up to 95 %, no condensation
Altitude	Up to 5,000 m; restrictions above 2,000 m require the current Siemens manual
Protection / approvals	Confirm enclosure, certificate and destination requirements against current Siemens documentation

Engineering note: Use the current Siemens system manual for mounting, grounding, clearances and environmental restrictions.

Selection

System role

Installation and selection sequence

Match the complete 6ES7215-1BG40-0XB0 article number and CPU 1215C AC/DC/relay variant.
Confirm the 85 to 264 V AC supply and relay-output load requirements.
Verify TIA Portal / STEP 7 version, CPU firmware and project migration requirements.
Check expansion modules, signal boards, communication modules and mounting limits in the current Siemens system manual.

Selection note: Do not infer interchangeability from a similar CPU family designation.

Verification

Before order

Verification checklist

Complete article number and suffix	CPU firmware and STEP 7 version
AC supply and relay load	Onboard analog ranges
PROFINET topology and address plan	Expansion and mounting compatibility
Current unit and nameplate photographs	Condition, testing, warranty, stock and dispatch terms

Match the full article number, electrical design, firmware, project software and expansion hardware before approval.

Commerciald

Written confirmation

Commercial information before payment

Every commercial commitment is confirmed against the exact article and quoted unit.

Stock status	Confirm before quotation for the exact article number and requested quantity.
Condition	New, used or refurbished status is stated in the written quotation.
Photos / nameplate	Current unit and nameplate photos are available on request.
Test statement	Available on request and subject to the agreed test scope.
Warranty	Confirmed in the formal quotation.
Dispatch	Confirmed after stock, destination and order approval are verified.
Payment	Supported methods are listed in the formal quotation.
Quote response	Subject to verification and request completeness.
Transaction trust	Seller details, quotation, invoice and payment instructions are available for review before payment.
Product status	Actual stock, unit condition, testing, warranty and dispatch are subject to verification.
