Product Name: SIMATIC S7-1200 SM 1222 Relay Output Module
Brand Name: Siemens
Model Number: 6ES7222-1HF30-0XB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
| Sales | Phone/Whatsapp | |
| Jim Pei | [email protected] | +86 18020776782 |
| Official article number | 6ES7222-1HF30-0XB0 |
| Manufacturer | Siemens AG |
| Product family | SIMATIC S7-1200 |
| Product type designation | SM 1222, DQ 8x relay/2 A |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| from backplane bus 5 V DC, max. | 120 mA |
| from load voltage L+, max. | 11 mA/relay coil |
| Power loss, typ. | 4.5 W |
| Number of digital outputs | 8 |
| in groups of | 2 |
| Short-circuit protection | No; to be provided externally |
| with resistive load, max. | 2A |
| on lamp load, max. | 30 W with DC, 200 W with AC |
| Rated value (DC) | 5 V DC to 30 V DC |
| Rated value (AC) | 5 V AC to 250 V AC |
| for signal "1" permissible range, max. | 2A |
| "0" to "1", max. | 10 ms |
| "1" to "0", max. | 10 ms |
| up to 50 °C, max. | 10 A; Current per mass |
| Number of relay outputs | 8 |
| Rated supply voltage of relay coil L+ (DC) | 24 V |
| Number of operating cycles, max. | mechanically 10 million, at rated load voltage 100 000 |
| with inductive load, max. | 2A |
| shielded, max. | 500 m |
| unshielded, max. | 150 m |
| Diagnostics function | Yes |
| Diagnostic alarm | Yes |
| for status of the outputs | Yes |
| for maintenance | Yes |
| between the channels | Relays |
| between the channels, in groups of | 2 |
| between the channels and backplane bus | 1 500 V AC for 1 minute |
| between different circuits | 750 V AC for 1 minute |
| IP degree of protection | IP20 |
| CE mark | Yes |
| FM approval | Yes |
| RCM (formerly C-TICK) | Yes |
| Fall height, max. | 0.3 m; five times, in product package |
| min. | 0 °C |
| max. | 55 °C |
| horizontal installation, min. | 0 °C |
| horizontal installation, max. | 55 °C |
| vertical installation, min. | 0 °C |
| vertical installation, max. | 45 °C |
| permissible temperature change | 5°C to 55°C, 3°C / minute |
| min. | -40 °C |
| max. | 70 °C |
| Storage/transport, min. | 660 hPa |
| Storage/transport, max. | 1 080 hPa |
| Operation at 25 ℃ without condensation, max. | 95 % |
| required front connector | Yes |
| Plastic | Yes |
6ES7222-1HF30-0XB0 is a Siemens SIMATIC S7-1200 SM 1222 Relay Output Module with eight relay outputs. Its official product data identifies 2 A per output and SM 1222 design. This Siemens SIMATIC S7-1200 product is engineered for dependable integration into compatible industrial automation systems. It supports clear product identification for engineering, replacement, and maintenance workflows. The genuine Siemens article helps maintain consistent system architecture and organized spare-parts planning. For sourcing and lifecycle support, 6ES7222-1HF30-0XB0 is a precisely identified Siemens industrial automation solution.
