Product Name: SIMATIC S7-300 FM 354 Positioning Module
Brand Name: Siemens
Model Number: 6ES7354-1AH01-0AE0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7354-1AH01-0AE0 SIMATIC S7-300 FM 354 Positioning Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC S7-300 FM 354 Positioning Module |
| Part Number | 6ES7354-1AH01-0AE0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated Supply Voltage | 24 V DC |
| Maximum Current Consumption | 350 mA |
| Encoder Supply (5 V) | 5 V DC, Max. 220 mA |
| 5 V Encoder Cable Length | Max. 35 m |
| Encoder Supply (24 V) | 24 V DC, Max. 300 mA |
| 24 V Encoder Cable Length | Max. 100 m |
| Digital Inputs | 4 |
| Input Voltage | 24 V DC |
| Signal "0" Level | -3 to +5 V |
| Signal "1" Level | +11 to +30 V |
| Input Current | Max. 2 mA ("0"), Typical 6 mA ("1") |
| Digital Outputs | 4 |
| Output Voltage | 24 V DC |
| Maximum Output Current | 0.6 A per output |
| Residual Current | Max. 2 mA |
| SSI Clock Frequency | Max. 1.25 Mbit/s |
| SSI Cable Length | Max. 100 m (10 m @ 1.25 Mbit/s) |
| Relay Contact Rating | 1 A / 50 V / 30 VA DC |
| Analog Output | -10 to +10 V |
| Analog Output Current | -3 to +3 mA |
| Analog Output Cable Length | Max. 35 m |
| Operating Temperature | 0 to +55 °C |
| Storage Temperature | -40 to +70 °C |
| Humidity Class | Class F |
| Connection Method | 20-pin Front Connector |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7354-1AH01-0AE0 SIMATIC S7-300 FM 354 Positioning Module is a high-performance positioning module designed for the SIMATIC S7-300 PLC platform. It provides precise motion and positioning control with integrated digital inputs and outputs, SSI encoder support, and an analog output ranging from -10 V to +10 V. Supporting 24 V DC operation and high-speed SSI communication, the module is ideal for controlling positioning axes in demanding industrial automation and motion control applications.
Compared with similar positioning control modules, the Siemens 6ES7354-1AH01-0AE0 offers precise motion control, flexible encoder connectivity, and seamless integration with SIMATIC S7-300 systems.
Q1: What is the 6ES7354-1AH01-0AE0 used for?
A1: 6ES7354-1AH01-0AE0 is used for precise positioning and motion control in SIMATIC S7-300 automation systems.
Q2: Which PLC platform is compatible with the 6ES7354-1AH01-0AE0?
A2: 6ES7354-1AH01-0AE0 is designed for the SIMATIC S7-300 PLC platform.
Q3: How many digital inputs and outputs does the 6ES7354-1AH01-0AE0 provide?
A3: 6ES7354-1AH01-0AE0 includes 4 digital inputs and 4 digital outputs.
Q4: What encoder interface does the 6ES7354-1AH01-0AE0 support?
A4: 6ES7354-1AH01-0AE0 supports SSI encoder communication with clock frequencies up to 1.25 Mbit/s.
Q5: What analog output range does the 6ES7354-1AH01-0AE0 provide?
A5: 6ES7354-1AH01-0AE0 provides an analog output range of -10 V to +10 V.
Q6: What is the maximum digital output current of the 6ES7354-1AH01-0AE0?
A6: 6ES7354-1AH01-0AE0 supports up to 0.6 A output current per digital output channel.
