Product Name: SIMATIC S7-1500F CPU 1516F-3 PN/DP
Brand Name: Siemens
Model Number: 6ES7516-3FN02-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
| TECHNICAL PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6ES7516-3FN02-0AB0 |
| Product type designation | CPU 1516F-3 PN/DP |
| HW functional status | FS01 |
| Firmware version | V2.9 |
| I&M data | Yes; I&M0 to I&M3 |
| Isochronous mode | Yes; Distributed and central; with minimum OB 6x cycle of 375 µs (distributed) |
| STEP 7 TIA Portal configurable/integrated from version | V17 (FW V2.9) / V16 (FW V2.8) or higher; with older TIA Portal versions |
| via dataset | Yes |
| Screen diagonal [cm] | 6.1 cm |
| Number of keys | 8 |
| Mode buttons | 2 |
| Rated value (DC) | 24 V |
| permissible range, lower limit (DC) | 19.2 V |
| permissible range, upper limit (DC) | 28.8 V |
| Reverse polarity protection | Yes |
| Mains/voltage failure stored energy time | 5 ms |
| Repeat rate, min. | 1/s |
| Current consumption (rated value) | 0.85 A |
| Current consumption, max. | 1.1 A |
| Inrush current, max. | 2.4 A; Rated value |
| I²t | 0.02 A²·s |
| Infeed power to the backplane bus | 12 W |
| Power consumption from the backplane bus (balanced) | 6.7 W |
| Power loss, typ. | 7W |
| Number of slots for SIMATIC memory card | 1 |
| SIMATIC memory card required | Yes |
| integrated (for program) | 1.5 Mbyte |
| integrated (for data) | 5 Mbyte |
| Plug-in (SIMATIC Memory Card), max. | 32 Gbyte |
| maintenance-free | Yes |
| for bit operations, typ. | 10 ns |
| for word operations, typ. | 12 ns |
| for fixed point arithmetic, typ. | 16 ns |
| for floating point arithmetic, typ. | 64 ns |
| Number of elements (total) | 8 000; Blocks (OB, FB, FC, DB) and UDTs |
6ES7516-3FN02-0AB0 is an original Siemens SIMATIC S7-1500F CPU 1516F-3 PN/DP for industrial automation systems. Official product data identifies its electrical, processing, communication, memory, and environmental characteristics for accurate engineering evaluation. The unit is designed for dependable integration within its designated automation platform. It supports reliable machine or process operation, diagnostics, commissioning, maintenance, and system modernization. The product is suitable for replacement projects and lifecycle support where order-number accuracy is essential. This page provides clear sourcing information for the 6ES7516-3FN02-0AB0 industrial automation product.
6ES7516-3FN02-0AB0 is used in industrial control systems that require dependable operation, communication, monitoring, or processing within the designated Siemens automation platform. Typical environments include manufacturing lines, process plants, material handling systems, utilities, and machine automation.
6ES7516-3FN02-0AB0 is suitable for commissioning, diagnostics, scheduled maintenance, spare-parts replacement, and lifecycle extension projects. It helps engineers maintain compatible installations and restore system availability with the correct order number.
