SIEMENS 6ES7650-1AM31-6XX0 failsafe marshalled termination assembly Original new

SIEMENS 6ES7650-1AM31-6XX0 failsafe marshalled termination assembly Original new

Product Name:failsafe marshalled termination assembly

Brand Name:SIEMENS

Model Number:6ES7650-1AM31-6XX0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7650 1am31 6xx0 failsafe marshalled termination assembly original new-1

Overview
Contact us
Specifications
Description
Applications
Control & Communication
Technical Data Summary
FAQ
Spares
Recommended Products

Overview

Brand Name:	SIEMENS
Model Number:	6ES7650-1AM31-6XX0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact us

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	6ES7650-1AM31-6XX0, Siemens failsafe relay output MTA for ET 200M systems, designed for 10-channel distributed switching control
System Type:	ET 200M interface module, enables remote relay termination and structured field wiring in automation panels
Output Channels:	10-channel relay outputs, supports Form C contact configuration for NO/NC switching reliability
Rated Voltage:	24 VDC supply input, stable operation across redundant and single-feed power configurations
Operating Voltage Range:	21.6–28.8 VDC, ensures stable performance under industrial voltage fluctuation conditions
Mounting Method:	35 mm DIN rail mounting, supports fast installation in standard control cabinets
Protection System:	Channel fusing with per-module protection, reduces fault propagation in relay circuits
Indicators:	LED status display for power and module health, supports fast visual diagnostics in field operation
Wiring Type:	Pluggable field terminals, supports 24–14 AWG wiring for simplified maintenance and replacement
Dimensions:	Approx. 224 mm width, installation-optimized structure for modular control panel integration
Weight:	Approx. 1 kg, lightweight industrial assembly for rack-based automation systems

Description

The 6ES7650-1AM31-6XX0 is a failsafe marshalled termination assembly engineered for ET 200M distributed I/O systems. It is designed to interface with 10-channel relay output modules, supporting both AC and DC switching applications in safety-critical automation environments.

Built with Form C relay architecture and redundant power feed capability, this module ensures stable signal routing and enhanced operational reliability. LED indicators provide clear visibility of power and system status, enabling fast diagnostics and simplified maintenance during operation.

The unit supports pluggable field wiring, individual channel fusing, and secure grounding via dedicated earth terminals. With SIL2 functional safety compliance and robust industrial-grade construction, it is suitable for demanding process and machine control systems requiring high availability and fault-tolerant relay switching performance.

Applications

Power plants: Used for turbine auxiliary control, relay switching, and generator protection signaling in distributed control systems.
Substations: Enables circuit breaker interlocking, bus protection logic, and remote relay actuation in power distribution networks.
Chemical plants: Supports process shutdown control, safety interlocks, and hazardous zone signal isolation for stable automation.
Steel mills: Applied in high-temperature environments for motor control, furnace relay logic, and heavy-duty switching tasks.
Machinery manufacturing plants: Used in production line automation, actuator switching, and modular equipment control systems.

Control & Communication

Relay-Based Switching Architecture: Uses Form C contacts for flexible NO/NC output control, improving compatibility with diverse field loads.
Redundant Power Design: Dual feed capability enhances system availability and reduces downtime risk in critical automation processes.
Integrated Diagnostics: LED indicators provide real-time status monitoring for power, module health, and channel operation.
Modular Field Connectivity: Pluggable terminals simplify wiring, maintenance, and rapid module replacement in industrial cabinets.
Safety-Oriented Design: SIL2 compliance ensures reliable operation in safety-related control loops and failsafe applications.

Technical Data Summary

Fail-Safe Relay Switching Architecture:
The 6ES7650-1AM31-6XX0 uses Form C relay outputs designed for reliable switching of AC and DC loads in safety-related automation systems, ensuring stable signal transfer in distributed I/O environments.
SIL2 Functional Safety Compliance:
The system is engineered in accordance with IEC 61508 SIL2 requirements, supporting defined safety integrity levels for industrial protection and emergency shutdown applications.
Redundant Power Input Capability:
Supports single or redundant 24 VDC supply configurations (21.6–28.8 VDC range), improving operational continuity and reducing risk of power-related downtime.
High Electrical Isolation Strength:
Provides reinforced and basic insulation between channels and supply circuits, ensuring safe separation of field signals up to industrial voltage levels.
Diagnostic and Status Monitoring:
Integrated LED indicators display module power, input status, and system health, enabling fast troubleshooting and reducing maintenance response time.
