Siemens 6ES7650-8EK80-0AA0 Digital Output Module

Siemens 6ES7650-8EK80-0AA0 Digital Output Module

Product Name: Digital Output Module

Brand Name: Siemens

Model Number: 6ES7650-8EK80-0AA0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7650 8ek80 0aa0 digital output module-1

Overview
Contact Us
Specifications
Description
Functions
Advantage
Why Choose US
Other Products
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales:	Email:	Whatsapp:
*Jim Pei*	*[email protected]*	*+86 18020776782*

Specifications

Product Name	Siemens 6ES7650-8EK80-0AA0 Digital Output Module
Manufacturer	Siemens
Product Type	Digital Output Module
Part Number	6ES7650-8EK80-0AA0
Place of shipment	Xiamen, China
Country of origin	Germany
Output Points	32-point digital output
Rated Load Voltage	24 V DC
Output Type	Digital Output
Short Circuit Protection	Yes, electronic short circuit protection
Short Circuit Response Threshold	Typical 1 A
Output Voltage (Signal 1)	Minimum L+ (-1.3 V)
Maximum Switching Frequency (Resistive Load)	100 Hz
Maximum Switching Frequency (Inductive Load DC13)	0.5 Hz
Maximum Switching Frequency (Lamp Load)	10 Hz
Maximum Power for Lamp Load	5 W
Load Resistance Range	48 Ω ~ 4 kΩ
Backplane bus current (5V DC)	60 mA max
Typical power consumption	9.3 W
Isolation test	500 V AC / 707 V DC
Permissible potential difference between loops	75 V DC / 60 V AC

Description

The Siemens 6ES7650-8EK80-0AA0 is a 32-point digital output module designed for industrial automation systems requiring reliable 24 VDC signal control. It provides 32 digital output channels for controlling actuators, valves, relays, indicators, and other field devices. The module supports a 24 VDC rated load voltage and features electronic short-circuit protection to improve system safety and reliability. With high switching capability, integrated protection functions, and stable performance within SIMATIC automation environments, the Siemens 6ES7650-8EK80-0AA0 is suitable for distributed control applications and industrial process automation.

Functions

Provides 32 digital output channels for controlling external devices.

Converts PLC control signals into 24 VDC switching outputs for field equipment.

Controls actuators, solenoid valves, relays, contactors, and indicator devices.

Provides electronic short-circuit protection to protect output channels from overload conditions.

Supports different load types including resistive, inductive, and lamp loads.

Enables reliable signal transmission between the automation controller and connected field devices.

Advantage

Compared with conventional digital output modules, the Siemens 6ES7650-8EK80-0AA0 provides a higher channel density, integrated protection features, and reliable switching performance for industrial automation applications. Its combination of 32-channel output capability and electronic protection helps simplify system design while improving operational reliability.

High Channel Density: Provides 32 digital output points in a single module, reducing installation space and simplifying cabinet wiring compared with lower-channel modules.
Integrated Short-Circuit Protection: Features electronic short-circuit protection with a typical response threshold of 1 A, improving equipment safety and reducing the risk of output damage.
Flexible Load Compatibility: Supports resistive, inductive, and lamp loads with different switching frequencies, allowing broader application possibilities.
Reliable 24 VDC Control: Designed for standard industrial 24 VDC systems, ensuring compatibility with common automation devices and field components.
Stable Switching Performance: Supports switching frequencies up to 100 Hz for resistive loads, enabling fast and accurate control operations.
Low System Power Consumption: Optimized power consumption helps reduce cabinet heat generation and improve system efficiency.
Industrial-Grade Reliability: Provides 500 V AC / 707 V DC isolation testing capability and supports reliable operation in demanding automation environments.
