Siemens 6FX2001-5QN25 PROFINET Multiturn Absolute Encoder
Siemens 6FX2001-5QN25 PROFINET Multiturn Absolute Encoder
Siemens 6FX2001-5QN25 PROFINET Multiturn Absolute Encoder
Siemens 6FX2001-5QN25 PROFINET Multiturn Absolute Encoder
Siemens 6FX2001-5QN25 PROFINET Multiturn Absolute Encoder
Siemens 6FX2001-5QN25 PROFINET Multiturn Absolute Encoder
Siemens 6FX2001-5QN25 PROFINET Multiturn Absolute Encoder
Siemens 6FX2001-5QN25 PROFINET Multiturn Absolute Encoder
Siemens 6FX2001-5QN25 PROFINET Multiturn Absolute Encoder
Siemens 6FX2001-5QN25 PROFINET Multiturn Absolute Encoder

Siemens 6FX2001-5QN25 PROFINET Multiturn Absolute Encoder

SIEMENS / Absolute Encoder
Product Name: PROFINET Multiturn Absolute Encoder
Brand Name:
Siemens
Model Number:
6FX2001-5QN25
Place of Origin:
Germany
Warranty:
12 Months
Appurtenance:
siemens 6fx2001 5qn25 profinet multiturn absolute encoder-1
Inquiry
  • Overview
  • Specifications
  • Contact info
  • Description
  • Function
  • FAQ
  • Our Company History
  • Why Choose Us
  • Other Products
  • Recommended Products

Commercial Terms

Minimum Order Quantity
1 Piece
Price
Contact for Jim
Packaging Details
Original new Factory Sealed
Delivery Time
3–7 Days
Payment Terms
T/T
Shipping Method
DHL / FedEx / UPS / TNT
Supply Ability
In stock

Specifications

颜色Model Number
6FX2001-5QN25
Operating voltage
10–30 V DC
Communication interface
PROFINET IO RT/IRT
Transmission rate
100 Mbit/s
Current FS15 resolution
30 bit
Legacy resolution
27 bit; verify function status and GSDML
Maximum mechanical speed
6000 rpm
Speed at stated ±1 LSB accuracy
5800 rpm
Sampling code
Gray
Transmission code
Binary
Encoder profile
PNO V4.1, Classes 1–4
Current standard telegrams
81–89
Siemens telegrams
860 / 862
Network connectors
2 × M12, 4-pin
Supply connector
1 × M12, 4-pin
Connector direction
Radial
Axial shaft load at n ≤6000 rpm
40 N maximum
Radial shaft load at n ≤6000 rpm
110 N maximum
Axial shaft load at n >6000 rpm
10 N maximum
Radial shaft load at n >6000 rpm
20 N maximum
Maximum angular acceleration
100000 rad/s²
Current rotor inertia
0.0000019 kg·m²
Vibration acceleration at 55–2000 Hz
100 m/s² maximum
Shock acceleration for 6 ms
1000 m/s² maximum
Housing protection
IP67
Shaft-entry protection
IP64
Operating temperature
-40 to +85 °C
Flange construction
Clamping flange
Shaft construction
Solid shaft
Conformity
CE, cULus

Contact info

Sales
Jim Pei
Phone/Whatsapp

Description

01

Siemens 6FX2001-5QN25 is a multiturn absolute encoder with a PROFINET IO interface. The current FS15 product is listed with 30-bit resolution. Earlier versions were specified with 27-bit resolution, so the function status must be checked before replacement. The encoder uses radial M12 connections and a clamping flange. Its absolute position information is transmitted to the connected automation system.

02

RT and IRT communication support integration into the configured PROFINET application. Preset and counting direction can be parameterized. The encoder profile determines how position information is exchanged with the controller. Isochronous operation is available for compatible configurations. Match the function status, telegram and GSDML file to the installed engineering project.

Function

A
Absolute position feedback
Multiturn acquisition supplies absolute rotary position information to a compatible automation controller.
B
Network integration
PROFINET IO RT and IRT support cyclic data transfer using the selected encoder telegram.
C
Parameter adaptation
Preset, direction and resolution settings allow the encoder data format to be matched to the engineering configuration.

FAQ

Q1Why do documents for 6FX2001-5QN25 show different resolutions?
Earlier documentation lists 27 bits, while the current FS15 listing specifies 30 bits. Confirm the actual function status before purchase.
Q2Which engineering file should accompany 6FX2001-5QN25?
Use a GSDML file suitable for the function status and selected encoder telegram.
Q3Can the counting direction of 6FX2001-5QN25 be changed?
Yes. Counting direction is parameterizable in the supported encoder configuration.
Q4Does 6FX2001-5QN25 provide a programmable limit-switch output?
No. The encoder data lists no parameterizable limit-switch function.
Q5Can you verify the label and connectors on 6FX2001-5QN25?
Yes. Request actual-item photos before ordering so the offered revision and connection arrangement can be checked.
Q6How quickly can a confirmed 6FX2001-5QN25 order ship?
We dispatch available stock immediately after receipt of payment and provide tracking information.
