Siemens 6GF3440-1CD10 SIMATIC MV440 SR Stationary Code Reader

Siemens 6GF3440-1CD10 SIMATIC MV440 SR Stationary Code Reader

Product Name: SIMATIC MV440 SR Stationary Code Reader

Brand Name: Siemens

Model Number: 6GF3440-1CD10

Place of Origin: Germany

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Appurtenance:

siemens 6gf3440 1cd10 simatic mv440 sr stationary code reader-1

Overview
Description
Specifications
Contact info
Commercial Term
FAQ
Other Products
Recommended Products

Read and verify codes at the point of production

The Siemens SIMATIC MV440 SR reads 1D and 2D codes with a 640 × 480 image sensor. OCR, object detection and code verification are optional licensed functions.

Before you order: Confirm the installed lens, lighting, protective barrel and software licenses; the reader is not supplied as a complete vision station.

Description

The MV440 SR is a stationary industrial code reader for traceability and identification tasks. Siemens lists Power over Ethernet and a variable image field, so the optical setup has to be matched to the actual code size and working distance.

A replacement should preserve image and job settings, network parameters, trigger wiring and the code-quality criteria used on the line. Re-test with representative labels or direct-part marks rather than relying on a single successful scan.

Installation & Integration

Confirm C-mount optics, illumination, trigger and Ethernet cabling. Siemens states IP67 only with the correct protective barrel and sealing caps; otherwise the rating is IP40.

Configuration & Programming

Back up the reader configuration and check which optional OCR, object-detection or verification licenses are actually installed.

Specifications

Product family

SIMATIC MV440

Device

MV440 SR stationary code reader

Image resolution

640 × 480 pixels

Code types

1D and 2D

Network power

Power over Ethernet

Optional functions

OCR, object detection and code verification

Protection

IP67 with protective barrel and sealing caps; otherwise IP40

Contact info

CONTACT

Jim Pei

[email protected]

+86 180 2077 6782

Commercial Term

Quotation

Current price and availability

Payment

T/T or agreed terms

Lead time

Confirmed with quotation

Shipping

DHL, FedEx, UPS or agreed freight

Warranty

12 months

FAQ

How can I confirm that 6GF3440-1CD10 will read the marks on my production line?

Test representative good and borderline marks at the actual working distance. Confirm lens, illumination, exposure and code settings before committing to a replacement.

What should I back up before replacing 6GF3440-1CD10?

Export the reader jobs, network settings, trigger and output configuration, and any installed license information. Photograph the lens, lighting and cable arrangement.

Why might 6GF3440-1CD10 power up but fail to decode a previously readable code?

Check focus, working distance, lighting, exposure, code-type selection and the condition of the protective window. Compare a known-good sample with the saved job settings.

What should I inspect if 6GF3440-1CD10 is visible on Ethernet but does not send results?

Verify the configured destination, trigger sequence and output mapping. Check the Ethernet link and the receiving controller or application before changing the reader job.

Can 6GF3440-1CD10 be mounted in a wet area without additional parts?

Do not assume so. Siemens states IP67 only when the specified protective barrel and sealing caps are fitted; confirm the complete mechanical assembly and site conditions.

What details should I send when requesting 6GF3440-1CD10?

Provide the exact order number, installed firmware and licenses, lens and light part numbers, expected code type, mounting photos and delivery requirements.
