Product Name: SCALANCE X212-2 Managed Industrial Ethernet Switch
Brand Name: Siemens
Model Number: 6GK5212-2BB00-2AA3
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
Fast response for industrial automation sourcing
| SalesJim Pei | Email[email protected] | Phone/Whatsapp+86 18020776782 |
| PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6GK5212-2BB00-2AA3 |
| Transfer rate / 1 | 10 Mbit/s |
| Transfer rate / 2 | 100 Mbit/s |
| Design of optical interface / for optical waveguide / at 100 Mbit/s | BFOC sockets (multimode up to 5 km) |
| Range / at the optical interface / depending on the optical fiber used | 0 … 5 km |
| Operating voltage / of signaling contacts / at DC / rated value | 24 V |
| Operating current / of signaling contacts / at DC / maximum | 0.1 A |
| Supply voltage / external | 24 V |
| Type of fusing / at input for supply voltage | 1,1 A / 33 V |
| Consumed current / maximum | 0.33 A |
| Active power loss / at 24 V / for DC | 7.92 W |
| during transport | 40 … +70 °C |
| Relative humidity / at 25 °C / without condensation / during operating | 95 % |
| Protection class IP | IP30 |
| Product-type designation | SCALANCE X212-2 |
| of the transmitter output | 19 … -14 dB |
| Optical sensitivity relative to 1 mW / of the receiver input / minimum | 34 dB |
| Attenuation / of fiber-optic cable transmission link / minimum | 0 dB |
| minimum | 18 V |
| maximum | 32 V |
| during operating | 40 … +60 °C |
| during storage | 40 … +70 °C |
| for EMC / from FM | FM3611: Class 1, Division 2, Group A, B, C, D / T4, CL.1, Zone 2, |
| for hazardous zone | EN 60079-0: 2006, EN60079-15: 2005, II 3 (2) G Ex nA [op is] IIC |
| for safety / of CSA and UL | UL 60950-1, CSA C22.2 No. 60950-1 |
| for hazardous area / of CSA and UL | ANSI / ISA 12.12.01, CSA C22.2 No. 213-M1987, CL. 1 / Div. 2 / |
| for emitted interference | EN 61000-6-4:2001 (Class A) |
| for power supply | 1 |
| for redundant power supply | 1 |
| Number of optical interfaces / for optical waveguide / at 100 Mbit/s | 2 |
| to website: Industry Online Support | http://support.automation.siemens.com |
| for network components or terminal equipment / maximum | 14 |
| for network components and terminal equipment | 12 |
| for signaling contact | 1 |
| Product component / fusing at power supply input | Yes |
|
01
6GK5212-2BB00-2AA3 is suitable for managed industrial Ethernet networks, PROFINET systems, machine networks, and control-cabinet communication. |
02
It can also support fiber uplinks, ring redundancy, diagnostics, monitoring, and network segmentation. |
|
