Product Name: SCALANCE XC224-4C G Managed Layer 2 IE Switch
Brand Name: Siemens
Model Number: 6GK5224-4GS00-2AC2
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
Fast response for industrial automation sourcing
| SalesJim Pei | Email[email protected] | Phone/Whatsapp+86 18020776782 |
| PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6GK5224-4GS00-2AC2 |
| transfer rate | 10, 100, 1000 Mbit/s |
| number of combo ports / with RJ45 interface for optical plug-in | 4; 1000 MBit/s SFPs |
| at DC / rated value | 24 V |
| supply voltage / 1 / rated value | 24 V |
| power loss [W] / 1 / rated value | 16.8 W |
| consumed current / 1 / maximum | 0.7 A |
| type of electrical connection / 1 / for power supply | 3-pole terminal block, permanently installed |
| fuse protection type / 1 / at input for supply voltage | 3,15 A / 125 V |
| during transport | 40 ... +85 °C |
| protection class IP | IP20 |
| product function / is supported / identification link | Yes; acc. to IEC 61406-1:2022 |
| Technical Product Detail Page | https://i.siemens.com/1P6GK5224-4GS00-2AC2 |
| during operation | 40 ... +70 °C |
| during storage | 40 ... +85 °C |
| at 25 °C / without condensation / during operation / | 95 % |
| material / of the enclosure | Polycarbonate (PC-GF10) / pressure die cast aluminum |
| telegram length / for Ethernet / maximum | 10240 byte |
| MTBF | 20 a |
| warranty period | 5a |
| to website: Selection guide for cables and connectors | https://support.industry.siemens.com/cs/ww/en/view/109766358 |
| number of 10/100/1000 Mbit/s RJ45 ports | 24 |
| for power supply | 1 |
| supply voltage / 1 / voltage range | 9.6 ... 31.2 |
| to web page: SiePortal | https://sieportal.siemens.com/ |
| to website: Industry Online Support | https://support.industry.siemens.com |
| product type designation | XC224-4C G |
| for network components or terminal equipment | 24; RJ45 |
| for SFP | 4 |
| for operator console | 1 |
| for signaling contact | 1 |
| product component / connection for redundant voltage supply | Yes |
| product component / 1 / fusing at power supply input | Yes |
| cascading in the case of a redundant ring / at reconfiguration | 50 |
| MIB support | Yes |
|
01
6GK5224-4GS00-2AC2 is suitable for full-Gigabit industrial Ethernet networks, control cabinets, production cells, and resilient plant communication. |
02
It can also support copper and fiber uplinks, PROFINET diagnostics, time synchronization, VLANs, and network redundancy. |
|
Q · How is the product packaged?
A · Original new Factory Sealed. |
Q · What is the delivery time?
A · Normally 3–7 days. Goods are dispatched promptly after payment is received. |
|
Q · Which payment terms are accepted?
A · T/T. |
Q · Which shipping methods are available?
A · DHL / FedEx / UPS / TNT. |
|
Q · Is the item available?
A · Yes. Supply Ability: In stock. |
Q · How do you ensure product quality?
A · The product is carefully checked before delivery and is supplied with quality-focused after-sales support. |
