Siemens 6GK5788-2GD00-0AB0 SCALANCE W788-2 M12 IWLAN Access Point

Siemens 6GK5788-2GD00-0AB0 SCALANCE W788-2 M12 IWLAN Access Point

Product Name: SCALANCE W788-2 M12 Industrial Wireless Access Point

Brand Name: Siemens

Model Number: 6GK5788-2GD00-0AB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Appurtenance:

siemens 6gk5788 2gd00 0ab0 scalance w788 2 m12 iwlan access point-1

Overview
Commercial Term
Specifications
Contact info
Description
Function
About Company
FAQ
Other Products
Recommended Products

Dual-Radio IWLAN Access for Rugged Industrial Installations

Siemens 6GK5788-2GD00-0AB0 is a SCALANCE W788-2 M12 industrial wireless access point with two radios, six external antenna ports and IP65 protection.

Use the exact Siemens order number 6GK5788-2GD00-0AB0 when matching an installed unit, project or service spare.

Commercial Term

QUOTATION	PAYMENT	LEAD TIME	SHIPPING	WARRANTY
Current price and availability	T/T or agreed terms	Confirmed with the quotation	DHL, FedEx, UPS or agreed freight	12 months

Specifications

Technical parameter	Value
Product type designation	SCALANCE W788-2 M12
Article number	6GK5788-2GD00-0AB0
Regional version	USA
Wireless radios	2
Wireless standards	IEEE 802.11a/b/g/h/n
Antenna connections	6 × N-CON
Ethernet interface	1 × M12, up to 1 Gbps
Power options	PoE or redundant 24 V DC
Degree of protection	IP65
Manufacturer	Siemens

Contact info

CONTACT

Jim Pei

[email protected]

+86 180 2077 6782

Description

With two IEEE 802.11a/b/g/h/n radios and six N-CON antenna ports, 6GK5788-2GD00-0AB0 can separate or combine industrial wireless coverage plans across 2.4 GHz and 5 GHz bands. The rugged M12 and IP65 design supports protected installation close to the machine network.

This order number is the USA regional version of 6GK5788-2GD00-0AB0. Radio approval, antenna selection, KEY-PLUG functions and the chosen power method must be aligned with the actual installation rather than copied from another W700 configuration.

Function

Dual-radio architecture	Plan two independent industrial wireless radio paths.
External antennas	Use six N-CON connections for the documented antenna arrangement.
Rugged networking	Connect through an M12 Gigabit Ethernet interface in an IP65 enclosure.
Flexible power	Use PoE or the documented redundant 24 V DC supply arrangement.

About Company

SupplyPLCs supports global industrial automation sourcing with exact-model review, product-condition confirmation and responsive quotation service.

Share the complete order number, installed-system context and destination with our team. We will coordinate availability, shipment options and the documentation available for the requested product.

FAQ

Q1. Can 6GK5788-2GD00-0AB0 be ordered for an installation outside the United States without a regional review?

Answer: No. Siemens identifies this order number as the USA version, so the radio approval and permitted channel plan must match the country of use before procurement continues.

Q2. How should the two radios of 6GK5788-2GD00-0AB0 be assigned in a plant with separate client and backbone traffic?

Answer: Start with a documented RF plan that defines band, channel and antenna purpose for each radio. Keep the six N-CON antenna paths traceable so commissioning does not merge two intended coverage zones.

Q3. Why might 6GK5788-2GD00-0AB0 power through Ethernet but remain unreachable from the wired network?

Answer: PoE can energize the access point while the M12 Ethernet link, IP settings or switch port remains incorrect. Confirm link status at both ends, then use the management path assigned to this access point before resetting configuration.

Q4. What should be preserved before moving a KEY-PLUG from 6GK5788-2GD00-0AB0 to a service unit?

Answer: Preserve the current configuration backup and record the plug identity and licensed iFeatures. Move the KEY-PLUG only within a controlled replacement procedure so the new access point does not start with an unexpected role.

Q5. When can an IP65 installation of 6GK5788-2GD00-0AB0 still fail environmental inspection?

Answer: IP65 depends on the complete installed condition. Unsealed M12 or N-CON interfaces, unsuitable cable glands or a damaged enclosure invalidate the expected protection, so all unused connections must be closed with approved protection.

Q6. Which evidence should accompany an RFQ for 6GK5788-2GD00-0AB0 used in an existing IWLAN cell?

Answer: Include the country of use, current firmware, KEY-PLUG status, radio-band plan and photographs of antenna and M12 connections. These details determine whether the USA dual-radio configuration fits the installed wireless design.
