Product Name: Hydraulic Servo Module
Brand Name: ABB
Model Number: SPHSS13
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | ABB SPHSS13 Hydraulic Servo Module |
| Manufacturer | ABB |
| Product Type | Hydraulic Servo Module |
| Part Number | SPHSS13 |
| Weight | 0.28kg |
| Estimated shipping dimensions | 3.5x31.5x17.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Servo-valve mode | ±300 mA |
| I/H converter mode | 4-20 mA or 20-160 mA |
| Excitation | 400 Hz – 15 kHz |
| Primary drive | 7 Vrms, 3.2 kHz ±0.2 kHz |
| Position Meter Output | 1 × 0-10 V or 4-20 mA |
| Digital Inputs | 3 opto-isolated 24 V DC |
| Update Rate | 1 ms (1 kHz) |
| Power Supply | +5 V DC 576 mA typ |
| Operating Temp | -25 … +70 °C (rack air) |
| Storage | -40 … +85 °C |
| Humidity | 5 … 95 % RH non-condensing |
The ABB SPHSS13 Hydraulic Servo Module is a high-precision industrial control module designed for advanced hydraulic motion control applications. It regulates servo valves and hydraulic actuators by converting control signals into precise hydraulic responses, enabling accurate positioning, force control, and dynamic motion regulation in complex industrial systems.
This module is widely used in high-performance automation environments such as turbine control, metal processing, and heavy machinery systems where fast response, stability, and precision are critical. Its real-time processing capability and servo control functions make it a key component in closed-loop hydraulic control architectures.
Hydraulic Servo Valve Control
Generates precise current signals (±300 mA) to control hydraulic servo valves for accurate motion regulation.
I/H Signal Conversion
Converts standard analog signals (4–20 mA or 20–160 mA) into hydraulic control signals for actuator operation.
Closed-Loop Position Control
Processes position feedback signals (0–10 V or 4–20 mA) for real-time hydraulic positioning accuracy.
High-Speed Control Processing
Executes control updates at 1 ms cycle time (1 kHz) for fast dynamic response.
Digital Input Processing
Handles 3 opto-isolated 24 V DC digital inputs for system control and status monitoring.
Excitation Signal Generation
Provides excitation frequencies between 400 Hz and 15 kHz for sensor and transducer operation.
System Integration Control
Coordinates hydraulic actuator behavior within ABB industrial automation systems.
Compared to other hydraulic servo control modules in the same class, the ABB SPHSS13 stands out for its fast 1 ms control cycle, wide signal compatibility, and high-precision closed-loop hydraulic regulation. It provides a highly responsive, stable, and versatile solution for demanding industrial motion control applications.
The ABB SPHSS13 Hydraulic Servo Module delivers high-speed and highly accurate hydraulic control performance, enabling precise regulation of servo valves and actuators in real-time industrial applications. Its 1 ms update cycle ensures rapid system response, allowing stable and dynamic control of complex mechanical movements.
With efficient power consumption of approximately 576 mA at +5 V DC and robust environmental tolerance, the module maintains consistent performance under demanding conditions. Its integration of multiple control and feedback signal types enhances system efficiency, reduces control latency, and improves overall hydraulic system stability in advanced industrial automation environments.
