Product Name: Power Supply Module
Brand Name: General Electric
Model Number: IC698PSA350
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The GE IC698PSA350 is a high-capacity power supply module designed for the GE PACSystems RX7i platform. Installed in Slot 0 of the rack, it provides reliable and regulated power to CPUs, I/O modules, communication modules, and other system components. With a total output capacity of 350 watts, the module is engineered to support demanding industrial automation applications that require stable power delivery and high system availability.
The IC698PSA350 accepts a wide range of AC and DC input voltages, making it suitable for diverse industrial power environments. It delivers multiple regulated output voltages, including +5 VDC, +12 VDC, and –12 VDC, while incorporating electrical isolation, overcurrent protection, and ride-through capability to ensure dependable operation in critical control systems. Its robust design and active product lifecycle make it a reliable choice for modern PACSystems installations.
| Product Name | GE IC698PSA350 Power Supply Module |
| Manufacturer | General Electric |
| Product Type | Power Supply Module |
| Part Number | IC698PSA350 |
| Weight | 2.02kg |
| Estimated shipping dimensions | 6.3x18.5x29.1cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Output Power | 350 Watts on total Three (3) outputs |
| Input Power | 125 Watts, typical; 150 Watts, maximum |
| Input Power | 437 watts (typical); 500 watts (maximum) |
| DC Output | +5 VDC: 4.875 to 5.25 volts, 0 to 60 amps; +12 VDC: 11.64 to 12.6 volts, 0 to 12 amps; –12 VDC: –12.6 to –11.64 volts, 0 to 4 amps |
| Output Current | 5.1 VDC: 0-60 Amperes +12 VDC: 0-12 Amperes - 12VDC: 0-4 Ampere |
| Isolation, input to all outputs | 250 VAC continuous; 1500 VAC for 1 minute |
| Ride Through Time | 15 milliseconds minimum (from loss of AC input) |
| Overcurrent Limit | +5 VDC output: 66A (typical); +12 VDC output: 15A (typical); –12 VDC output: 4.6A (typical) |
| Wiring Terminals | Input Terminals: AWG #16 (1.3 mm2) GND Terminals: #12 AWG (3.3 mm2) |
| Nominal Rated Voltage | 120/240 VAC, 125 VDC |
| Power | 100 watts |
| Input Voltage Range | 85 to 264 VAC; 100-150VDC |
| AC Input Frequency | 47-63 Hz |
| Temperature | 0-60 degrees celsius |
| Ride through time | 15 ms |
| Holdup time | 5 ms |
| Slot Assignment | Slot 0 |
| Product lifecycle | Active |
| GND Wire | 12 AWG |
| Isolation | 1500 Volts DC |
High power capacity: delivers up to 350 W total output, supporting large and complex automation systems
Wide input voltage range: accepts 85–264 VAC or 100–150 VDC, offering exceptional installation flexibility
Multiple output rails: provides +5 VDC, +12 VDC, and –12 VDC from a single power supply module
Strong current capability: supports up to 60 A on the +5 VDC output for high-density system configurations
Enhanced system protection: includes overcurrent protection and high-voltage isolation features
Compared with similar products: offers higher output capacity, broader input voltage compatibility, and stronger current delivery than many standard industrial PLC power supplies
Reliable operation: ride-through and holdup functions help minimize disruptions caused by brief power fluctuations
Compared with similar PLC power supply modules, the IC698PSA350 provides superior output power, greater input flexibility, enhanced protection features, and higher current capacity, making it an excellent solution for demanding industrial automation systems.
The IC698PSA350 is fully compatible with GE PACSystems RX7i platforms and is specifically designed to operate in Slot 0 of RX7i racks. It seamlessly supplies power to CPUs, communication modules, I/O modules, and other compatible system components, ensuring stable operation across the entire automation architecture.
The module integrates smoothly into both new and existing RX7i installations and supports a wide range of industrial power infrastructures through its broad AC and DC input voltage compatibility. Its standardized power distribution design and protection features enable reliable interoperability with high-density control systems, communication networks, and distributed automation applications.
