| TECHNICAL PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6AV2145-6KB20-0AS0 |
| Product type designation | TP1000F Mobile |
| Display design | TFT widescreen, LED backlighting |
| Screen diagonal | 10.1 in |
| Number of display colors | 16,777,216 |
| Display resolution | 1,280 x 800 pixels |
| Backlight MTBF at 25 °C | 50,000 h |
| Backlight dimming range | 0-100% |
| Rated supply voltage | 24 V DC |
| Permissible supply voltage range | 19.2-28.8 V DC |
| Rated current consumption | 450 mA |
| Starting current inrush I²t | 0.2 A²·s |
| Typical active power input | 11 W |
| Available user memory | 12 MB |
| Industrial Ethernet interfaces | 1 |
| PROFINET interfaces | 1 |
| USB interfaces | 1 x USB 2.0 |
| SD card slots | 1 |
| PROFINET IO support | Yes |
| PROFIsafe support | Yes |
| EtherNet/IP support | Yes |
| TCP/IP support | Yes |
| DHCP support | Yes |
| SNMP support | Yes |
| MODBUS support | Yes |
| Degree of protection | IP65 all-round |
| Safety performance level | PLe (ISO 13849-1) |
| Safety integrity level | SIL 3 (IEC 61508) |
| Operating temperature range | 0-45 °C |
| Storage/transport temperature range | -20-60 °C |
| Maximum operating humidity | 90% |
| Runtime languages | 32 |
| Bit messages | 4,000 |
| Variables per device | 2,048 |
| Message buffer entries | 1,024 |
6AV2145-6KB20-0AS0 is a Siemens SIMATIC HMI TP1000F Mobile safety panel with a 10.1-inch TFT widescreen and clear 1,280 x 800 visualization. It operates from a 24 V DC supply and provides PROFINET/Industrial Ethernet connectivity for industrial communication. The mobile operator panel combines touch operation with safety-oriented controls for flexible machine access. It supports modern visualization, alarm handling, recipe management, diagnostics, and secure operator workflows. The ergonomic portable design helps personnel monitor and control equipment close to the process. This Siemens mobile HMI is suitable for reliable industrial automation sourcing, replacement, maintenance, and system integration.
6AV2145-6KB20-0AS0 is used where operators need to move between stations while keeping visualization and control close to the machine. Typical environments include production lines, assembly systems, material-handling equipment, packaging machinery, and flexible manufacturing cells.
6AV2145-6KB20-0AS0 is suited to industrial systems that combine local HMI operation with safety-related operator actions. It supports commissioning, diagnostics, maintenance, process observation, and controlled interventions in machine and plant automation.
