Product Name: ELECTRONIC MODULE
Brand Name: SIEMENS
Model Number: 6ES7134-4GB52-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7134-4GB52-0AB0 ELECTRONIC MODULE |
| Manufacturer | SIEMENS |
| Product Type | ELECTRONIC MODULE |
| Part Number | 6ES7134-4GB52-0AB0 |
| Weight | 0.05kg |
| Estimated shipping dimensions | 1.5x5.5x8.3cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Current, relative to input range, (+/-) | 0.30% |
| Address space per module, max. | 4 byte |
| Number of analog inputs | 2 |
| Cycle time (all channels) max. | 0.25 ms |
| Input resistance (0 to 20 mA) | 106 Ω |
| Rated value (DC) | 24 V |
| from load voltage L+ (without load), max | 225 mA |
| from backplane bus 3.3 V DC, max. | 10 mA |
| Power loss, typ. | 2.5 W |
| Resolution with overrange | 16 bit |
| Diagnostics wire break at | 4 to 20 mA |
| Industrial Signal Acquisition Module | Industrial Measurement Module |
| ET200S I/O Module | Analog Signal Interface |
| Current Input Module | Factory Automation Module |
| 4-20mA Input Module | 16-Bit Analog Module |
| Industrial Automation Module | PLC Expansion Module |
| Process Control Input Module | Industrial Control Hardware |
| Siemens PLC Module | Signal Monitoring Module |
| High-Speed Analog Module | Precision Input Module |
| Distributed I/O Module | Automation Input Device |
The 6ES7134-4GB52-0AB0 is a high-performance electronic module designed for Siemens distributed automation systems. Featuring two analog input channels, it enables precise acquisition and processing of analog current signals for industrial monitoring and control applications.
With 16-bit resolution, fast conversion speed, and integrated diagnostics, the module delivers accurate measurement performance for process automation environments. Its compact design and reliable operation make it suitable for manufacturing, process control, and industrial monitoring systems.
Analog Signal Acquisition
Captures and processes analog current signals from field instruments and sensors.
Two-Channel Input Processing
Provides two independent analog input channels for simultaneous signal monitoring.
High-Resolution Measurement
Delivers 16-bit resolution with overrange support for accurate data acquisition.
Current Signal Monitoring
Supports industrial current input applications including 4–20 mA measurement systems.
Fast Data Conversion
Offers a maximum cycle time of 0.25 ms for rapid signal processing.
Wire Break Detection
Provides diagnostic monitoring for wire break conditions in 4–20 mA circuits.
Distributed I/O Integration
Integrates seamlessly into Siemens distributed automation architectures.
Process Control Support
Supplies reliable analog measurement data for process monitoring and control applications.
Compared with similar analog input modules, the 6ES7134-4GB52-0AB0 offers higher measurement accuracy, faster signal processing, and integrated diagnostics, making it ideal for demanding industrial applications.
High Measurement Accuracy: Delivers ±0.30% accuracy for reliable process monitoring.
Fast Response Performance: Processes all channels with a cycle time of up to 0.25 ms.
16-Bit Resolution: Provides detailed and precise analog signal acquisition.
Integrated Wire Break Diagnostics: Improves maintenance efficiency and system reliability.
Compact Design: Saves cabinet space in distributed automation systems.
Low Power Consumption: Optimizes overall system energy efficiency.
Reliable Industrial Operation: Designed for continuous use in demanding automation environments.
How many analog inputs does 6ES7134-4GB52-0AB0 provide?
The 6ES7134-4GB52-0AB0 provides two analog input channels.
What resolution does 6ES7134-4GB52-0AB0 support?
The 6ES7134-4GB52-0AB0 supports 16-bit resolution with overrange capability.
Does 6ES7134-4GB52-0AB0 support wire break diagnostics?
Yes, the 6ES7134-4GB52-0AB0 includes wire break detection for 4–20 mA signals.
What is the cycle time of 6ES7134-4GB52-0AB0?
The 6ES7134-4GB52-0AB0 has a maximum cycle time of 0.25 ms for all channels.
What type of signals can 6ES7134-4GB52-0AB0 measure?
The 6ES7134-4GB52-0AB0 is designed for analog current signal measurement, including standard industrial current loops.
Is 6ES7134-4GB52-0AB0 suitable for process control applications?
Yes, the 6ES7134-4GB52-0AB0 is widely used in process automation, monitoring, and industrial control systems.
