Home > Products > SIEMENS > SIMATIC S7 Series
Product Name: SIMATIC S7-300 FM 351 Positioning Module
Brand Name: Siemens
Model Number: 6ES7351-1AH01-0AE0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7351-1AH01-0AE0 SIMATIC S7-300 FM 351 Positioning Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC S7-300 FM 351 Positioning Module |
| Part Number | 6ES7351-1AH01-0AE0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Supply Voltage | 24 V DC |
| Current Consumption | Max. 350 mA |
| Encoder Supply | 5 V DC / 24 V DC |
| 5 V Encoder Output | Max. 350 mA, cable length max. 32 m |
| 24 V Encoder Output | Max. 400 mA per channel, cable length max. 100 m |
| Digital Inputs | 8 channels |
| Digital Input Voltage | Rated 24 V DC; Signal 0: -3 to +5 V; Signal 1: +11 to +30 V |
| Digital Input Current | Signal 0: max. 2 mA; Signal 1: typ. 6 mA |
| Digital Outputs | 8 channels |
| Output Protection | Short-circuit protection available |
| Output Voltage | 24 V DC |
| Output Current Range | 5 mA to 600 mA (0–60 °C, with UPmax) |
| Residual Current | Max. 0.5 mA (Signal 0) |
| Operating Temperature | 0 °C to +60 °C |
| Storage / Transport Temperature | -40 °C to +70 °C |
| Connection Type | 1 × 20-pin front connector |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7351-1AH01-0AE0 SIMATIC S7-300 FM 351 Positioning Module is a high-performance positioning module designed for the SIMATIC S7-300 automation system. It provides precise positioning control with support for 5 V DC and 24 V DC encoder signals, along with 8 digital inputs and 8 digital outputs for flexible machine control. Featuring short-circuit-protected outputs, reliable signal processing, and wide temperature tolerance, it is suitable for demanding motion control applications in industrial automation systems.
Compared with similar S7-300 positioning modules, the Siemens 6ES7351-1AH01-0AE0 provides accurate positioning control, flexible signal handling, and reliable operation for industrial motion applications.
Q1: Does the 6ES7351-1AH01-0AE0 provide output protection?
A1: 6ES7351-1AH01-0AE0 includes short-circuit protection to improve system safety and reliability.
Q2: Which automation system is compatible with the 6ES7351-1AH01-0AE0?
A2: 6ES7351-1AH01-0AE0 is designed for the SIMATIC S7-300 PLC system.
Q3: What encoder signals does the 6ES7351-1AH01-0AE0 support?
A3: 6ES7351-1AH01-0AE0 supports both 5 V DC and 24 V DC encoder supplies for different feedback applications.
Q4: How many digital inputs does the 6ES7351-1AH01-0AE0 have?
A4: 6ES7351-1AH01-0AE0 provides 8 digital input channels for machine control and signal processing.
Q5: How many digital outputs does the 6ES7351-1AH01-0AE0 provide?
A5: 6ES7351-1AH01-0AE0 provides 8 digital output channels with short-circuit protection.
Q6: What is the operating voltage of the 6ES7351-1AH01-0AE0?
A6: 6ES7351-1AH01-0AE0 operates with a 24 V DC supply voltage.
