Siemens 6SE7090-0XX85-1DA0 SIMOVERT MASTERDRIVES CUR Module

Siemens 6SE7090-0XX85-1DA0 SIMOVERT MASTERDRIVES CUR Module

Product Name: SIMOVERT MASTERDRIVES CUR Control Module

Brand Name: Siemens

Model Number: 6SE7090-0XX85-1DA0

Place of Origin: Austria

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Overview
Legacy Drive Matching
Description
Specifications
Service Diagnostics
Commercial Term
Contact info
FAQ
Other Products
Recommended Products

Legacy CUR control module for SIMOVERT MASTERDRIVES infeed and regenerative feedback units

Exact spare and software check: Match the complete CUR order number, installed power unit, board and connector revision, software or EPROM identity and parameter archive. Do not energize an unmatched board or assume that a SINAMICS migration is a board-only replacement.

This replacement control module is specified for SIMOVERT MASTERDRIVES infeed and infeed/regenerative feedback units. Siemens identifies associated software 6SW1701-0DA14 for T434E support and lists the product as a cancelled spare with migration toward LV SINAMICS.

Legacy Drive Matching

Board identity, host power unit and software must be matched as one service package before the CUR module is installed.

Host unit identity

Record the complete infeed or regenerative unit order number, rating, cabinet function and machine reference.

Board revision

Photograph the CUR label, connector orientation, EPROM or software labels and all installed option boards.

Software scope

Confirm the required 6SW1701-0DA14 software support and retain the approved parameter and commissioning archive.

Description

6SE7090-0XX85-1DA0 is a CUR control-module spare for legacy SIMOVERT MASTERDRIVES line-side units. The official product record specifically associates software 6SW1701-0DA14 with T434E support.

Because the module is cancelled and application-sensitive, procurement should be based on the original unit nameplate, board labels, installed software and the complete infeed or regenerative unit order number. Preserve the drive parameter and fault history before removal.

Specifications

Product type designation	SIMOVERT MASTERDRIVES CUR Control Module
Order number	6SE7090-0XX85-1DA0
Application	Infeed and infeed/regenerative feedback units
Associated software	6SW1701-0DA14
Software support reference	T434E
Lifecycle status	Product cancelled since 6 October 2011
Migration reference	Migration toward LV SINAMICS
Service status	Spare part with repair or replacement service options
Net weight	0.400 kg
Packaging dimensions	26 x 33 x 9.5 cm
Country of origin	Austria
Commodity / class	85049090; Siemens product class D

Service Diagnostics

Capture evidence while the legacy drive can still communicate; a board exchange should follow safe isolation and controlled checks.

Fault record

Save active and historical faults, parameter values, ready-state information and the sequence that causes the trip.

Safe isolation

Follow the drive discharge and lockout procedure, prove the DC link is safe and label each connector before handling the board.

Controlled restart

Check seating, connectors and software identity before power-up, then verify the host unit state before enabling regeneration.

Commercial Term

Quotation

Current price and availability

Payment

T/T or agreed terms

Lead time

Confirmed with quotation

Shipping

DHL, FedEx, UPS or agreed freight

Warranty

12 months

Contact info

TEMP

CONTACT

Jim Pei

[email protected]

+86 180 2077 6782

FAQ

How can I confirm that 6SE7090-0XX85-1DA0 is the correct CUR spare for my MASTERDRIVES unit?

Match the full CUR order number, host infeed or regenerative unit order number, board and connector revision, EPROM or software label and cabinet wiring. Provide clear photos and the original unit nameplate before ordering.

Why is software 6SW1701-0DA14 important when replacing 6SE7090-0XX85-1DA0?

Siemens identifies 6SW1701-0DA14 as the associated software for T434E support. Confirm that the software, parameter set and board revision belong to the installed application before commissioning the spare.

What should I back up before removing 6SE7090-0XX85-1DA0?

Save the parameter and commissioning archive, active and historical faults, host unit order number, board labels, software or EPROM identity and connector photos. Keep the original module available until the replacement passes functional tests.

Why can the host unit remain not ready after 6SE7090-0XX85-1DA0 is installed?

With the drive safely isolated, recheck board seating, every keyed connector, software or EPROM compatibility and the restored parameter set. On power-up, record the first fault and host-unit state before repeating resets or changing hardware.

What information should I provide for diagnosis or quotation of 6SE7090-0XX85-1DA0?

Provide the complete host-unit and CUR order numbers, rating plate, board revision, software labels, parameter backup status, active faults, cabinet function and clear photos of both sides and all connectors.

Can 6SE7090-0XX85-1DA0 be replaced directly by a SINAMICS component?

No board-level drop-in migration should be assumed. Siemens points to LV SINAMICS migration, which requires an engineered review of the power section, regenerative function, motor and line data, control interfaces, safety, cabinet mechanics and commissioning software.
