AB 1395-A65N-C1-PZ Digital DC Drive

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Product Parameters

Product Name	AB 1395-A65N-C1-PZ Digital DC Drive
Manufacturer	AB
Product Type	Digital DC Drive
Part Number	1395-A65N-C1-PZ
Weight	18.2kg
Estimated shipping dimensions	31x27.5x60cm
Place of shipment	Xiamen, China
Country of origin	USA
Input Voltage	230V AC ±10%, 3‑phase
Input Frequency	50/60 Hz ±3 Hz
Output Horsepower	5 HP (continuous)
Output Current	Not specified for this variant
Contactor Type	Standard (1‑15 HP rating)
Port A Option	115V AC discrete adapter
Control Protocols	Modbus, CANopen
Overload Capacity	150% for 60 sec, 200% for 10 sec, 260% for 5 sec
Operating Temperature	0°C to 55°C
Storage Temperature	0°C to 65°C
Humidity	5% to 95% (non‑condensing)

Introduction

The Allen-Bradley 1395-A65N-C1-PZ is a microprocessor-based digital DC drive from the Bulletin 1395 series, engineered to deliver precise speed and torque control for DC motor applications. Operating on a 230V AC, 3-phase power supply, this non-regenerative drive provides 5 HP output and is widely used in industrial systems such as conveyors, extruders, material handling equipment, and processing machinery where reliable motor performance and accurate control are essential.

Designed with a modular architecture, the 1395-A65N-C1-PZ supports optional adapter boards that expand its input and output capabilities to meet diverse application requirements. The drive combines advanced motor control algorithms, programmable operating parameters, and comprehensive protection functions to ensure smooth operation, enhanced productivity, and long-term system reliability. Although discontinued by the manufacturer, it remains a valuable solution for maintaining and upgrading legacy Allen-Bradley DC drive systems.

Functions

Provides precise speed regulation and torque control for DC motors.
Supports programmable acceleration and deceleration times from 0.1 to 6,554 seconds.
Allows configuration of preset speeds, jog speeds, and current limit settings.
Offers high-performance speed regulation with encoder or tachometer feedback.
Supports flexible machine integration through digital and analog I/O interfaces.
Monitors motor operating conditions in real time to improve system reliability.
Detects field loss and feedback loss conditions to prevent unexpected motor operation.
Provides overload handling capabilities for demanding industrial applications.
Enables customized control strategies through optional adapter board expansion.
Supports industrial automation systems requiring stable and repeatable motor performance.

Features

230V AC ±10%, 3-phase input power supply
5 HP continuous output rating
Non-regenerative digital DC drive design
Microprocessor-based control architecture
Speed regulation accuracy of up to 0.01% with encoder feedback
Speed regulation accuracy of 0.5% with DC tachometer feedback
Programmable acceleration and deceleration ramps
Integrated preset speed and jog speed functions
Port A equipped with a 115V AC discrete adapter board
4 digital inputs, 2 digital outputs, 4 analog inputs, and 4 analog outputs
Instantaneous phase-sensitive overcurrent protection
Programmable motor thermal overload protection
Field loss monitoring with adjustable delay settings
Encoder and tachometer feedback loss detection
Built-in under-voltage protection
Operating temperature range from 0°C to 55°C

Advantage

Superior Speed Regulation

Compared with many conventional DC drives, the 1395-A65N-C1-PZ delivers exceptional speed regulation performance, achieving up to 0.01% accuracy when used with encoder feedback. This level of precision helps improve product consistency, process stability, and overall production quality in demanding industrial applications.

High Overload Capability

The 1395-A65N-C1-PZ offers stronger overload performance than many comparable DC drives. Its ability to withstand 150% overload for one minute, 200% for ten seconds, and 260% for five seconds enables the drive to handle temporary peak loads without unnecessary shutdowns, improving operational continuity.

Flexible Expansion Options

Unlike many fixed-I/O drive systems, the 1395-A65N-C1-PZ features a modular design that supports optional adapter boards. This flexibility allows users to customize digital and analog I/O configurations to better match application-specific control requirements.

Comprehensive Protection Functions

The drive incorporates multiple protection mechanisms, including overcurrent protection, motor overload protection, field loss detection, feedback loss monitoring, and under-voltage protection. These integrated safeguards help reduce equipment damage, minimize downtime, and extend motor service life.

Proven Reliability for Legacy Systems

As part of Allen-Bradley’s well-established Bulletin 1395 family, the 1395-A65N-C1-PZ has earned a reputation for dependable operation in industrial environments. It remains a preferred replacement and maintenance solution for facilities operating legacy DC motor control systems.

FAQ

Q1: What is the primary application of the 1395-A65N-C1-PZ?

A: The 1395-A65N-C1-PZ is designed for precise speed and torque control of DC motors in applications such as conveyors, extruders, material handling equipment, and industrial production machinery.

Q2: Does the 1395-A65N-C1-PZ support regenerative braking?

A: No. The 1395-A65N-C1-PZ is a non-regenerative DC drive, meaning it does not return braking energy to the AC supply. Dynamic braking resistors may be used when faster stopping performance is required.

Q3: What input power is required for the 1395-A65N-C1-PZ?

A: The 1395-A65N-C1-PZ operates with a 230V AC ±10%, 3-phase power supply at 50/60 Hz.

Q4: What I/O capabilities are included with the 1395-A65N-C1-PZ?

A: The 1395-A65N-C1-PZ includes a 115V AC discrete adapter that provides 4 digital inputs, 2 digital outputs, 4 analog inputs, and 4 analog outputs for flexible machine integration.

Q5: What protection features are available in the 1395-A65N-C1-PZ?

A: The 1395-A65N-C1-PZ includes instantaneous overcurrent protection, programmable motor overload protection, field loss detection, feedback loss detection, di/dt limiting, and under-voltage protection to ensure safe and reliable operation.
