Specifications

Official article number	6EP1334-3BA10
Manufacturer	Siemens AG
Product family	SITOP PSU200M
type of the power supply network	1-phase and 2-phase AC
supply voltage at AC	Set by means of selector switch on the device
supply voltage 1 at AC	120 ... 230 V
supply voltage 2 at AC	230 ... 500 V
input voltage 1 at AC	85 ... 264 V
input voltage 2 at AC	176 ... 550 V
wide range input	Yes
overvoltage overload capability	1300 Vpeak, 1.3 ms
buffering time for rated value of the output current in the event of	25 ms
operating condition of the mains buffering	at Vin = 120/230 V, typ. 150 ms at Vin = 400 V
line frequency	50/60 Hz
line frequency	47 ... 63 Hz
at rated input voltage 120 V	4.4 A
at rated input voltage 230 V	2.4 A
at rated input voltage 500 V	1.1 A
current limitation of inrush current at 25 °C maximum	35 A
I2t value maximum	4 A²·s
fuse protection type	T 6.3 A (not accessible)
fuse protection type in the feeder	Recommended miniature circuit breaker at 1-phase operation: from 6 A (10 A)
voltage curve at output	Controlled, isolated DC voltage
output voltage at DC rated value	24 V
at output 1 at DC rated value	24 V
output voltage adjustable	Yes; via potentiometer
adjustable output voltage	24 ... 28.8 V
relative overall tolerance of the voltage	3%
on slow fluctuation of input voltage	0.1 %
on slow fluctuation of ohm loading	0.1 %
maximum	50 mV
maximum	200 mV
display version for normal operation	Green LED for 24 V OK
type of signal at output	relay contact (normally open, contact rating (SELV (ES1) must be observed):
behavior of the output voltage when switching on	Overshoot of Vout approx. 3 %
response delay maximum	1s
typical	50 ms
rated value	10 A
rated range	0 ... 10 A; +60 ... +70 °C: Derating 2%/K (at 120 V, 230 V) or 3.5%/K (at 400 V)
supplied active power typical	240 W
at short-circuit during operation typical	30 A
at short-circuit during operation	25 ms
on short-circuiting during the start-up typical	12 A
bridging of equipment	Yes; switchable characteristic
number of parallel-switched equipment resources for increasing	2
efficiency in percent	91 %
at rated output voltage for rated value of the output	24 W
during no-load operation maximum	6W
relative control precision of the output voltage with rapid	0.1 %
relative control precision of the output voltage load step of	3%
load step 50 to 100% typical	2 ms
load step 100 to 50% typical	2 ms
maximum	5 ms
design of the overvoltage protection	< 35 V
property of the output short-circuit proof	Yes
design of short-circuit protection	Alternatively, constant current characteristic approx. 12 A or latching shutdown
typical	12 A
display version for overload and short circuit	LED yellow for "overload", LED red for "latching shutdown"
galvanic isolation between input and output	Yes
galvanic isolation	Safety extra-low output voltage Uout acc. to EN 60950-1 and EN 50178
operating resource protection class	Class I
maximum	3.5 mA
typical	0.32 mA
protection class IP	IP20
for emitted interference	EN 55022 Class B
for mains harmonics limitation	EN 61000-3-2
for interference immunity	EN 61000-6-2
CE marking	Yes
UL approval	Yes; cULus-Listed (UL 508, CSA C22.2 No. 107.1), File E197259
UKCA marking	Yes
EAC approval	Yes
Regulatory Compliance Mark (RCM)	Yes
NEC Class 2	No
SEMI F47	Yes
BIS	Yes; R-41183539
CB-certificate	Yes
MTBF at 40 °C	1 055 408 h
IECEx	No
ATEX	No
ULhazloc approval	No
FM registration	No
shipbuilding approval	Yes
American Bureau of Shipping Europe Ltd. (ABS)	Yes
French marine classification society (BV)	No
Det Norske Veritas (DNV)	Yes
Lloyds Register of Shipping (LRS)	No
Environmental Product Declaration	Yes
total	763.9 kg
during manufacturing	12.6 kg
during operation	751 kg
after end of life	0.18 kg
during operation	-25 ... +70 °C; With natural convection; startup tested starting from -40 °C
during transport	-40 ... +85 °C
during storage	-40 ... +85 °C
environmental category according to IEC 60721	Climate class 3K3, 5 ... 95% no condensation
type of electrical connection	screw terminal
at input	L, N, PE: 1 screw terminal each for 0.2 ... 2.5 mm² single-core/finely stranded
at output	+, -: 2 screw terminals each for 0.2 ... 2.5 mm²
for auxiliary contacts	13, 14 (alarm signal): 1 screw terminal each for 0.14 ... 1.5 mm²
width × height × depth of the enclosure	70 × 125 × 121 mm
installation width × mounting height	70 mm × 225 mm
top	50 mm
bottom	50 mm
left	0 mm
right	0 mm
fastening method	Snaps onto DIN rail EN 60715 35x7.5/15
DIN-rail mounting	Yes
S7 rail mounting	No
wall mounting	No
housing can be lined up	Yes
net weight	0.8 kg
electrical accessories	Buffer module
to website: Industry Mall	https://mall.industry.siemens.com
to web page: selection aid TIA Selection Tool	https://www.siemens.com/tstcloud
to web page: power supplies	https://siemens.com/sitop
to website: CAx-Download-Manager	https://siemens.com/cax
to website: Industry Online Support	https://support.industry.siemens.com
other information	Specifications at rated input voltage and ambient temperature +25 °C (unless
security information	Siemens provides products and solutions with industrial cybersecurity functions
Version	Classification
eClass	14 27-04-07-01
eClass	12 27-04-07-01
eClass	9.1 27-04-07-01
eClass	9 27-04-07-01
eClass	8 27-04-90-02
eClass	7.1 27-04-90-02
eClass	6 27-04-90-02
ETIM	10 EC002540
ETIM	9 EC002540
ETIM	8 EC002540
ETIM	7 EC002540
IDEA	4 4130
UNSPSC	15 39-12-10-04
Manufacturer Declara-	Declaration of Con-
tion	formity
General Product Approval	Maritime application
Miscellaneous	BIS CRS
last modified:	11/1/2025

Description

6EP1334-3BA10 is a Siemens SITOP PSU200M 24 V DC 10 A Stabilized Power Supply documented with 120/230-500 V AC input, 24 V DC output, and 10 A rated output. These verified characteristics identify the correct hardware for its designated Siemens automation environment. The product performs its assigned role within compatible industrial control, communication, drive, or power architectures. It supports structured engineering, commissioning, and maintenance workflows. Clear Siemens article identification helps technicians source the correct component for replacement and lifecycle service. For professional automation projects, 6EP1334-3BA10 provides a dependable, product-specific solution for compatible installations.

Functions

01 Conditions and distributes electrical power for compatible automation equipment.

02 Supports reliable operation of connected control-system components.

03 Helps maintain continuity of the DC supply in industrial installations.

04 Provides product-specific protective behavior for abnormal operating conditions.

05 Supports orderly integration in control cabinets and power assemblies.

06 Helps simplify commissioning of the designated power architecture.

07 Supports maintenance personnel with clear product identification and status behavior.

08 Enables replacement of the matching Siemens power component.

09 Contributes to dependable machine and process-control operation.

10 Supports lifecycle maintenance of compatible automation systems.
