Product Name: SIMATIC S7-400 CPU 416-2
Brand Name: Siemens
Model Number: 6ES7416-2XN05-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
| TECHNICAL PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6ES7416-2XN05-0AB0 |
| Hardware product version | 04 |
| Firmware version | V5.3 |
| Programming package | STEP7 V 5.3 SP2 or higher with HW update |
| CiR synchronization time, basic load | 100 ms |
| CiR synchronization time, time per I/O slave | 10 µs |
| 24 V DC | No ; Power supply via system power supply |
| from CPU, max. | Not relevant for 400 series (300 series set) |
| from backplane bus 5 V DC, typ. | 0.9 A |
| from backplane bus 5 V DC, max. | 1.1 A |
| from backplane bus 24 V DC, max. | 300 mA ; 150 mA per DP interface |
| from interface 5 V DC, max. | 90 mA ; At each DP interface |
| Power loss, typ. | 4.5 W |
| Power loss, max. | 5W |
| Battery operation | Not relevant |
| Backup current, typ. | 125 µA ; (up to 40 °C) |
| Backup current, max. | 550 µA |
| Backup time, max. | See reference manual, module data, Chapter 3.3 |
| Feeding of external backup voltage to CPU | 5 to 15 VDC |
| integrated | 5.6 Mbyte |
| integrated (for program) | 2.8 Mbyte |
| integrated (for data) | 2.8 Mbyte |
| expandable | No |
| expandable FEPROM | Yes ; with Memory Card (FLASH) |
| expandable FEPROM, max. | 64 Mbyte |
| integrated RAM, max. | 1 Mbyte |
| expandable RAM | Yes ; with Memory Card (RAM) |
| expandable RAM, max. | 64 Mbyte |
| present | Yes |
| with battery | Yes ; all data |
| without battery | No |
| for bit operations, typ. | 30 ns |
| for word operations, typ. | 30 ns |
| for fixed point arithmetic, typ. | 30 ns |
| for floating point arithmetic, typ. | 90 ns |
6ES7416-2XN05-0AB0 is an original Siemens SIMATIC S7-400 CPU 416-2 for industrial automation systems. Official product data identifies its electrical, processing, communication, memory, and environmental characteristics for accurate engineering evaluation. The unit is designed for dependable integration within its designated automation platform. It supports reliable machine or process operation, diagnostics, commissioning, maintenance, and system modernization. The product is suitable for replacement projects and lifecycle support where order-number accuracy is essential. This page provides clear sourcing information for the 6ES7416-2XN05-0AB0 industrial automation product.
6ES7416-2XN05-0AB0 is used in industrial control systems that require dependable operation, communication, monitoring, or processing within the designated Siemens automation platform. Typical environments include manufacturing lines, process plants, material handling systems, utilities, and machine automation.
6ES7416-2XN05-0AB0 is suitable for commissioning, diagnostics, scheduled maintenance, spare-parts replacement, and lifecycle extension projects. It helps engineers maintain compatible installations and restore system availability with the correct order number.
