Product Name: Universal Backplane
Brand Name: General Electric
Model Number: IC695CHS016
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The GE IC695CHS016 is a 16-slot Universal Backplane designed for the GE PACSystems RX3i automation platform. It serves as the central mounting and communication infrastructure for CPU, I/O, power supply, and communication modules, enabling efficient data exchange and power distribution throughout the control system. Its rack-mounted design provides a stable and scalable foundation for building medium- to large-scale industrial automation systems.
Engineered for flexibility and reliability, the IC695CHS016 supports module hot-swapping, integrated grounding, and Universal Backplane technology, allowing a wide range of RX3i modules to operate within the same rack. With support for 24 VDC input power and installation in IP54 or higher-rated enclosures, the backplane is suitable for demanding industrial environments requiring continuous operation and easy maintenance.
| Product Name | GE IC695CHS016 Universal Backplane |
| Manufacturer | General Electric |
| Product Type | Universal Backplane |
| Part Number | IC695CHS016 |
| Weight | 2.06kg |
| Estimated shipping dimensions | 60.5x14x2.1cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Installation clearance | 102 mm (4.0 in) on all sides |
| Required Protection for Installation | NEMA/UL Type 1 (IP20) |
| Minimum Required Clearance for Installation | 102 millimeters (4 inches) on all sides |
| Current rating | 600 mA at 3.3 VDC, 240 mA at 5 VDC |
| Internal Power Used | 240 milliamps at 5 Volts DC, 600 milliamps at 3.3 Volts DC |
| Input Terminals | TB1; Terminal 7: Isolated 24VDC Terminal 8: Isolated ground |
| Grounding bar | Integrated |
| Module Hot-swap | Supported |
| Lifecycle status | Active |
| Mounting | Rack |
| No of slots | Sixteen (16) |
| Number of Slots | 16 |
| Input | +24 Volts |
| Recommended wire size | 14 to 22 AWG |
| Enclosure | IP54 or greater |
High expansion capacity: 16 available slots accommodate large and complex automation systems
Hot-swap capability: allows module replacement without shutting down the entire system, reducing downtime
Universal Backplane technology: supports flexible integration of multiple RX3i module types in a single rack
Integrated grounding bar: improves electrical stability and simplifies installation
Robust industrial design: suitable for installation in IP54 or higher-rated enclosures
Compared with similar products: offers greater flexibility, easier maintenance, and improved scalability than conventional fixed-function backplanes
Long-term availability: active lifecycle status ensures continued support and system expansion opportunities
Compared with similar backplane systems, the IC695CHS016 provides superior scalability, hot-swap functionality, flexible module compatibility, and easier maintenance, making it an ideal foundation for modern PACSystems RX3i automation applications.
The IC695CHS016 is fully compatible with the GE PACSystems RX3i platform and supports a wide range of RX3i CPUs, I/O modules, communication modules, and power supplies. Its Universal Backplane architecture allows different module types to coexist within the same rack, providing maximum flexibility for system design and future expansion.
The backplane integrates seamlessly with RX3i automation networks and supports interoperability across distributed control architectures through compatible communication modules. Its standardized mounting, power distribution, and communication infrastructure ensure smooth integration into both new installations and existing PACSystems environments, simplifying system upgrades and expansion projects.
